2. Gently slide the blade in until you feel it start to resist as the edge connectors begin to mate.
This will occur approximately 1/8" (3mm) before the blade is fully seated. At this stage, the
Middle Retaining Bolt should be used to pull the blade into its final mated position.
3. Using a 3/16" socket, fully tighten the Middle Retaining Bolt. This bolt secures the blade to the
chassis from the interior, ensuring proper contacts between the blade and the router
backplane.
Caution
— You must first fully tighten the Middle Retaining Bolt before tightening the screws on the
ULTRIX-MODX-IO. Not doing so will damage the blade, the connectors on the backplane, or both.
ENET 1
ULTRIX-MODX-IO
A
REF
A
B
1
4
ENET 2
Figure 6 Ultrix Rear Panel — Location of Middle Retaining Bolt on the Blade
4. Using a Phillips screwdriver, tighten the retaining screws located on the left and right sides of
the blade.
Tightening these screws is required to ensure proper alignment between the blade and the
router backplane.
ENET 1
ULTRIX-MODX-IO
REF
A
1
4
ENET 2
5. Power on the router as outlined in the ULTRIX-FR1, ULTRIX-FR2, and ULTRIX-FR5 Installation
Guide.
Notice
— The router automatically powers on when power is applied.
Installing in an ULTRIX-FR12 Chassis
Before installing the ULTRIX-MODX-IO, you must first ensure the required slot is available in the
ULTRIX-FR12. This may required you to either remove the blank plate or an installed blade from the
required slot in the rear panel of the router. Both methods are outlined in this section.
