About This Machine; Name Of Each Part; Front Side - Develop ineo 4050 Quick Manual

2.1

About this machine

2 Overview of This Machine
2.1 About this machine
2.1.1

Name of each part

Front side

No. Name
1 Control Panel
2 Automatic Document Feeder (ADF)
2-a ADF Feed Cover
2-b Document Guide
2-c Document Feed Tray
2-d Document Output Tray
2-e Document Stopper
3 USB Host Port
4 Manual Feed Tray
5 Tray 1
6 Output Tray
7 Data Indicator
*
A USB hub can be connected to the USB Host Port. Only one USB memory device and one Authentication
Unit (IC card type) can be simultaneously connected to a USB hub.
NOTICE
When using a USB hub, use a self-powered hub. If you use a bus-powered hub, the hub could malfunction.
ineo 4050/4750
2-b
2-a
1
7
6
5
*
2 2-c
2-d
2-e
3
4
2
