EVAL-LTC9101-2 EVALUATION BOARD PHOTO
Table 1. EVAL-LTC9101-2-KIT Options
Demo Kit
IEEE Standard
EVAL-LTC9101-2A
802.3at
EVAL-LTC9101-2
802.3bt
analog.com
Figure 1. EVAL-LTC9101-2 Evaluation Board Photo
Daughter Card
Mother Board
DC3159A-D
DC3017A-B
DC3159A-C
DC3017A-B
EVAL-LTC9101-2
LTC9101 Version
2-Pair Ports
-2A
48
-2
0
4-Pair Ports
0
24
