Hardware Installation and Reference Guide
Figure 3-6 Securing the Mounting Bracket to a Wall
Wall anchor
Align the feet on the rear of the AP over the mounting holes on the bracket.
(2)
Figure 3-7 Aligning the AP with the Mounting Bracket
Caution
Install the Ethernet cable before sliding the AP into the mounting bracket.
Slide the AP into the mounting bracket in the opposite direction against the arrow on
(3)
the mounting bracket until the AP clicks into space.
Diameter 6.5 mm
DC power
supply
Screw
PoE power
supply
Install the Ethernet cable before
sliding the AP into the mounting
bracket.
26
Installing the Access Point
