1
Install the batteries.
Open the battery
compartment.
2
Install the wiper motor and sensors.
Remove restrictor and
protective sticker.
1-970-498-1500
Aqua TROLL 600 Quickstart Guide
Getting Started
Install alkaline batteries.
Remove dust cap from
wiper motor or motor
port plug.
Box Contents
1 Documentation and software
2 Wiper motor and brush/wiper
3 Aqua TROLL 600 sonde
4 Water quality sensors (2 of 4)
5 Water quality sensors (2 of 4)
6 RDO sensor cap
7 Accessory supplies
8 pH/ORP sensor maintenance supplies
9 Extra sensors
10 D-cell alkaline batteries
11 Instrument tools
Use Allen wrench to
remove and check
desiccant color. If pink,
replace.
Apply lubricant to
O-rings.
1
Close battery
compartment. LCD
screen should activate.
Insert motor/port plug
into center port.
www.in-situ.com
Advertisement
Related Manuals for In-situ Aqua TROLL 600
Summary of Contents for In-situ Aqua TROLL 600
- Page 1 Aqua TROLL 600 Quickstart Guide Box Contents 1 Documentation and software 2 Wiper motor and brush/wiper 3 Aqua TROLL 600 sonde 4 Water quality sensors (2 of 4) 5 Water quality sensors (2 of 4) 6 RDO sensor cap 7 Accessory supplies 8 pH/ORP sensor maintenance supplies...
- Page 2 Apply vacuum flat edge on instrument instrument in other. Push grease to O-ring. connector. and twist until click. When using a conductivity sensor and turbidity sensor together, install them side-by-side to maximize performance. 1-970-498-1500 www.in-situ.com...
- Page 3 Connect. devices. An iOS device To connect to another automatically connects instrument, press Disconnect and then to the closest In-Situ instrument. Choose or Add Device. VuSitu displays a list of available connections. VuSitu displays the Tap the serial number Connected Instrument...
- Page 4 600. If you have questions, contact In-Situ Technical Support for assistance. • Use D-cell alkaline batteries. • Do not use the Aqua TROLL 600 in any manner not specified by the manufacturer. • Do not use batteries of different ages or types.
