You must have a Temperature or Conductivity/Temperature sensor installed to use the
pH/ORP sensor.
Install sensor.
1
Rinse sensor with clean
water before use.
Install sensor. Do not
twist.
Calibrate and deploy.
2
For detailed calibration instructions, see the instruction manual or quick start guide for your
In-Situ instrument.
Page 1
Aqua TROLL 500/600 pH/ORP Sensor Overview
The pH/ORP sensor is a combination single-junction electrode that contains a
platinum ORP sensor, glass pH sensing bulb, replaceable junction, and refillable
reference electrolyte solution.
Getting Started
Remove restrictor from
the instrument.
Place restrictor on
instrument in calibration
mode.
970-498-1500
Instruction Sheet
Remove sensor port plug
if installed. Do not twist.
www.in-situ.com
Lubricate o-ring at
bottom of sensor.
2020-08-13 | 0063472
Advertisement
Related Manuals for In-situ Aqua TROLL 500 pH/ORP
Summary of Contents for In-situ Aqua TROLL 500 pH/ORP
- Page 1 Place restrictor on Install sensor. Do not instrument in calibration twist. mode. Calibrate and deploy. For detailed calibration instructions, see the instruction manual or quick start guide for your In-Situ instrument. Page 1 970-498-1500 www.in-situ.com 2020-08-13 | 0063472...
- Page 2 If the sensor fails to calibrate after you replace the fill solution, replace the reference junction. Page 2 970-498-1500 www.in-situ.com 2020-08-13 | 0063472...
- Page 3 Calibration Kit (1 L each pH 4, pH 7, pH 10, DI water) 0032080 Quick Cal (4 x 250 mL) 0033250 Reference Junction Kit (3 junctions, 60 mL reference filling solution) 0078990 pH Storage Solution (500 mL) 0065370 Page 3 970-498-1500 www.in-situ.com 2020-08-13 | 0063472...
