CA 163 Speaker • Setup Guide (Continued)

Mounting Options

The CA 163 Loudspeaker can can be wall mounted with either of the following mounting options:
SMK LP CA Low-Profile Mounting Bracket Kit — mounts flat; can be adjusted for ±2.5° and ±5° tilt.
SMK PT CA Pan-Tilt Mounting Bracket Kit
NOTE:
Do not discard the Mounting Template or foam end caps until entire installation process is complete.
SMK LP CA Low-Profile Mounting Bracket Kit
The SMK LP CA Low-Profile Bracket allows for the CA 163 column loudspeaker to be positioned flat against the wall (less than 1"
off the surface), where little to no tilt is required (up to ±5° tilt max).
Carriage
Bolts (2)
Washers (2)
Figure 3. SMK LP CA Low-Profile Bracket Kit
Mounting the Low Profile Wall Brackets
1. Position SMK LP CA mounting template (see
figure 4) to the wall where you want to mount
the speaker. Use a pushpin or piece of tape to
secure the top end of the template to the wall
( ). Ensure the template is level, then secure
1
the bottom end with an additional pushpin or
piece of tape ( ).
2
2. Determine which mounting location will be used.
a. For flat 0° mounting, use "A" mounting
positions, labeled 0°.
b. For speaker requiring some tilt, use "B"
mounting positions, labeled 2.5°-5°.
3. Mark four screw locations or drill four pilot holes
through the template (
included) to secure two Low-Profile Brackets to
the wall.
4. When marking or drilling is complete, remove
the template from the wall. DO NOT discard the
template.
5. If necessary, cut a hole in the wall to route cables
to the CA 163 speaker.
6. If not done already, drill four pilot holes through
the marked locations on the wall.
7. Use appropriate hardware to securely attach the
low-profile brackets to the wall (
using #14 x 1 3/4" self-tapping wood or metal
screws and 1/4" SAE washers).
DO NOT mount Low-Profile Brackets over the
Mounting Template.
2
(see page 4) — allows up to 15° tilt and ±55° panning.
Lock Primery
Knurled
Knobs (2)
), for four screws (not
3
) (example –
4
Extension Low-Profile
Knobs (2)
Brackets (2)
Secure with tape
or thumbtack.
TOP
(Side B)
Slide into end-cap foam
in this direction
e
CA 163
Mounting Template
For use with
SMK LP CA
Low-Pro le Mount
(See side A for pan-tilt mounting options)
Scan for installation video
0˚
Mount Location (A)
0˚
MOUNT
LOCATION
A
ALIGN
KNOB
HERE
2.5˚ - 5˚
Mount Location (B)
2.5˚ - 5˚
MOUNT
LOCATION
B B
ALIGN
KNOB
HERE
0˚
Mount Location (A)
0˚
MOUNT
LOCATION
A
ALIGN
KNOB
HERE
2.5˚ - 5˚
Mount Location (B)
2.5˚ - 5˚
MOUNT
LOCATION
B
ALIGN
KNOB
HERE
Slide into end-cap foam in this direction
P/N 68-3759-51 Rev. B
Secure with
additional tape
or thumbtack.
Figure 4. Installing the SMK LP CA Low-Profile Brackets
1 1 1
Template
(Side B)
B B
5 ˚
˚ -
2 . 5
T
U N
M O N
T I O
C A
L O
Mark or drill holes
B B
through template.
N
IG
A L O B
K N
R E
H E
2 2 2
Low-Pro le Bracket
4 4 4
Low-Pro le Bracket
4 4 4
Use mounting
screws (not included)
to secure brackets.
3 3 3
