Controller Operation
CAN
REDUNDANT
AMSC 2
(MULTISET ONLY)
CAN 1
26
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
1.0 mm²
AWG 18
1.0 mm²
AWG 18
1.0 mm²
AWG 18
1.0 mm²
AWG 18
1.0 mm²
AWG 18
1.0 mm²
AWG 18
1.0 mm²
AWG 18
1.0 mm²
AWG 18
0.5 mm²
AWG 20
0.5 mm²
AWG 20
0.5 mm²
AWG 20
0.5 mm²
AWG 20
0.5 mm²
AWG 20
0.5 mm²
AWG 20
0.5 mm²
AWG 20
Shield
0.5 mm²
AWG 20
0.5 mm²
AWG 20
Shield
0.5 mm²
AWG 20
0.5 mm²
AWG 20
Shield
0.5 mm²
AWG 20
0.5 mm²
AWG 20
Shield
Deep Sea Electronics® G8601 Controller Owner's Manual
DC Output E
DC Output F
DC Output G
DC Output H
DC Output I
DC Output J
DC Output K
DC Output L
Sensor Common Return for
Analog Sensor Inputs A,B,C,D
Analog Sensor Input A
Analog Sensor Input B
Analog Sensor Input C
Analog Sensor Input D
CAN Port H
CAN Port L
CAN Port Screen
Magnetic Pickup Positive
Magnetic Pickup Negative
Magnetic Pickup Screen
ECU Port H
ECU Port L
ECU Port Screen
DSENet® Expansion B
DSENet® Expansion A
DSENet® Expansion Screen
