Fault
Calibration Fault
Charge Alt Failure
IEEE 37.2 – 27 DC Undervoltage Relay
Charger Fan Locked
Charger High Temperature
Charger Mains High Current
Charger ID 0 to 3 Common Warning
Charger Mains High Voltage
Charger Mains Low Voltage
Charger Voltage Drop Charging Cable Output 1
Charger Voltage Drop Charging Cable Output 2
Coolant Temp High
IEEE C37.2 – 26 Apparatus Thermal Device
DEF Level Low
Coolant Temp High
IEEE C37.2 – 26 Apparatus Thermal Device
Digital Input A to L
DPTC Filter
Earth Fault
IEEE C37.2 – 51G or 51N
Deep Sea Electronics® G8601 Controller Owner's Manual
Description
The module detected that its internal calibration has failed. The
unit must be sent back to DSE to be investigated and repaired.
Contact DSE Technical Support for more details.
The module detected that the output voltage of the charge alter-
nator had fallen below the Charge Alternator Warning Trip level
for the configured delay timer.
The module detected that a battery charger connected by DSE-
Net® had a Charger Failure alarm.
The module detected that a battery charger connected by DSE-
Net® had a High Temperature alarm.
The module detected that a battery charger connected by DSE-
Net® had a Mains High Current alarm.
NOTE: Due to module configuration the alarm message that ap-
pears on the display may be different. For further details of mod-
ule configuration, contact your Authorized Industrial Service
Dealer (IASD).
The module detected that a battery charger connected by DSE-
Net® had issued a Common Warning Alarm.
The module detected that a battery charger connected by DSE-
Net® had a Mains High Voltage alarm.
The module detected that a battery charger connected by DSE-
Net® had a Mains Low Voltage alarm.
The module detected that a battery charger connected by DSE-
Net® had issued a Voltage Drop Charging Cable alarm on its
Output 1.
The module detected that a battery charger connected by DSE-
Net® had issued a Voltage Drop Charging Cable alarm on its
Output 2.
The module detected that the engine coolant temperature had
risen above the High Coolant Temperature Pre-Alarm Trip level
after the Safety On Delay timer had expired.
The module received a fault condition from the engine ECU
alerting about the DEF level.
The module detected that the engine coolant temperature had
risen above the High Coolant Temperature Pre-Alarm Trip level
after the Safety On Delay timer had expired.
NOTE: Due to module configuration the alarm message that ap-
pears on the display may be different. For further details of mod-
ule configuration, contact your Authorized Industrial Service
Dealer (IASD).
The module detected that a digital input configured to create a
fault condition became active and the appropriate LCD mes-
sage is displayed.
The module received a fault condition from the engine ECU
alerting that the DPF/DPTC had activated.
