Controller Operation

Fault Alarms

SeeTable 3-1 for condition of each entry as it is defined by the user configuration.
Table 3-1. Faults
Fault
Battery Detect Failure
Battery Failure Detection Output 1
Battery Failure Detection Output 2
Battery High Current Output 1
Battery High Current Output 2
Battery High Temperature Output 1
Battery High Temperature Output 2
Battery High Voltage Output 1
Battery High Voltage Output 2
Battery Low Voltage Output 1
Battery Low Voltage Output 2
Battery Temperature Sensor Fail Output 1
Battery Temperature Sensor Fail Output 2
AVR Maximum Trim Limit
Battery High Voltage
IEEE 37.2 – 59 DC Overvoltage Relay
Battery Low Voltage
IEEE 37.2 – 27 DC Undervoltage Relay
12
Description
The module detected that a battery charger connected by DSE-
Net® had issued a Battery Detect Failure alarm.
The module detected that a battery charger connected by DSE-
Net® had issued a Battery Failure Detection alarm on its Output
1.
The module detected that a battery charger connected by DSE-
Net® had issued a Battery Failure Detection alarm on its Output
2.
The module detected that a battery charger connected by DSE-
Net® had issued a Battery High Current alarm on its Output 1.
The module detected that a battery charger connected by DSE-
Net® had issued a Battery High Current alarm on its Output 2.
The module detected that a battery charger connected by DSE-
Net® had issued a Battery High Temperature alarm on its Out-
put 1.
The module detected that a battery charger connected by DSE-
Net® had issued a Battery High Temperature alarm on its Out-
put 2.
The module detected that a battery charger connected by DSE-
Net® had issued a Battery High Voltage alarm on its Output 1.
The module detected that a battery charger connected by DSE-
Net® had issued a Battery High Voltage alarm on its Output 2.
The module detected that a battery charger connected by DSE-
Net® had issued a Battery Low Voltage alarm on its Output 1.
The module detected that a battery charger connected by DSE-
Net® had issued a Battery Low Voltage alarm on its Output 2.
The module detected that a battery charger connected by DSE-
Net® had issued a Battery Temperature Fail alarm on its Output
1.
The module detected that a battery charger connected by DSE-
Net® had issued a Battery Temperature Fail alarm on its Output
2.
The module's AVR output has reached its limit whilst attempting
to control the generator to produce more kvars whilst in parallel.
This indicates a fault with either the AVR (including connection
error), setting of SW2, or that the alternator has reached its
maximum capacity.
The module detected that its DC supply voltage had risen above
the Plant Battery Overvolts Warning Trip level for the configured
delay timer.
The module detected that its DC supply voltage had fallen be-
low the Plant Battery Undervolts Warning Trip level for the con-
figured delay timer.
