Module programming for convenience features only (skip transponder)
Refer to "LED diagnostics and troubleshooting" for more information and for troubleshooting purposes.
Ensure vehicle is in a safe location and cannot move forward during programming. For vehicles
1
equipped with a manual transmission, make sure the gearshift is in the neutral position.
The harnesses must be connected in this exact order:
1. Connect the 14-pin.
2
2. Connect the 12-pin.
3. Connect the 10-pin.
When the LED turns on solid red, proceed with the next step.
Press the programming button five (5) times.
3
The LED turns ON solid orange.
4
Press once (1) on the Push-to-Start (PTS) button to turn the ignition ON, then the LED shuts OFF.
5
Press once (1) more on the PTS button to turn the ignition OFF.
You have successfully completed the module programming sequence.
12
403.TL17 1.00 2022 Toyota Sienna Hybrid (Smart Key)
©2023 Directed. All rights reserved.
Solid
Connect
Solid
Press &
Release x5
Off
