Directed Directechs DB3 Installation Manual page 9

Input 10-pin black connector (H3)
Module
Conn./Pin Color
H3/1 Green
H3/2 Blue
H3/3 Red/White
H3/4 White/Violet
H3/5 Violet/Black
H3/6 White/Black
H3/7 Pink/White
H3/8 Violet
H3/9 Pink
H3/10 Blue/White
D2D 4-pin white connector (H4)
Module
Conn./Pin
H4/1
H4/2
H4/3
H4/4
RF 2-pin white connector (H5)
Module
Conn./Pin
H5/1
H5/2
9 403.TL17 1.00 2022 Toyota Sienna Hybrid (Smart Key)
©2023 Directed. All rights reserved.
Description
(-) W2W Only - Lock Input
(-) W2W Only - Unlock Input
(-) W2W Only - Trunk Input
IMO Data Input
No Connection
No Connection
(+) W2W Only - Parking Light Input
(+) W2W Only - Starter Input
(+) W2W Only - Ignition Input
(-) W2W Only - Ground When Running (Status) Input
Color
Blue
Black
Green
Red
Color
N/A
N/A
Connects To
Wire Location
Remote Starter
Remote Starter
Remote Starter
Hybrid Vehicle Control ECU right of dash fuse box, black 54 pin plug, pin 39
No Connection
No Connection
Remote Starter
Remote Starter
Remote Starter
Remote Starter
(+/-) Wire Color
Data Green (IMO)
Description
(Data) TX
(-) Ground
(Data) RX
(+) 12 Volt
Description
No Connection
No Connection
