Module Programming For Convenience Only (Skip Transponder) - Directed DIRECTECHS DB3 Installation Manual

Module programming for convenience features only (skip transponder programming)
Refer to "LED diagnostics and troubleshooting" for more information and for troubleshooting purposes.
To connect the module:
Ensure vehicle is in a safe location and cannot move forward during programming. For vehicles
1
equipped with a manual transmission, make sure the gearshift is in the neutral position.
Connect the 10-pin, 12-pin main power harness and 14-pin harnesses to the module.
2
Wait until the LED turns on solid red then proceed to the next step.
Press the programming button five (x5) times.
3
The LED turns ON solid orange.
4
Turn ignition ON and wait until the LED turns OFF.
5
Turn ignition OFF.
You have successfully completed the module programming sequence.
11
403.SUBARU1 1.38 2008 Subaru Impreza
©2023 Directed. All rights reserved.
Solid
Connect
Solid
Press &
Release x5
Key IN
START
Off
Key OUT
START
