Carton Contents; Assembly - Craftsman TINE DETHATCHER 486.24312 Owner's Manual

40" front mount tine dethatcher
Hide thumbs

Advertisement

CARTON CONTENTS
1. Mounting Arms (2)
2. Lift Handle
3. Angle Mounting Brackets (2)
4. Lift Handle Bracket
5. Hitch Bracket
6. Axle
1
5
6
Stop engine and let muffler cool before
attempting to install dethatcher hitch
brackets.
TOOLS REQUIRED FOR ASSEMBLY
(2) 1/2" Wrenches
(2) 9/16" Wrenches

ASSEMBLY

2
9
8
7
7. Wheel
8. Mounting Shaft
9. Lift Handle Arm
10. Handle Lock Bracket
11. Tine Shield
12. Frame Mount Bracket
3
10
REMOVAL OF PARTS FROM CARTON
• Remove all parts and hardware packages from the
carton. Lay out all parts and hardware and identify
using the illustrations on pages 3 and 4.
REMOVAL OF PARTS FROM TRACTOR
• Remove any front mounted attachments which may
be installed on your tractor.
• Mark all loose parts and save for reassembly.
4
4
11
12
