Advantech UNO-3300G Series User Manual
Advantech UNO-3300G Series User Manual

Advantech UNO-3300G Series User Manual

Intel core i7/celeron processors embedded automation pc, with 2x pci(e)/ pci extension slots

Advertisement

Quick Links

User Manual
UNO-3300G Series
Intel® Core® i7/Celeron
Processors Embedded
Automation PC, with 2x PCI(e)/
PCI Extension Slots

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UNO-3300G Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Advantech UNO-3300G Series

  • Page 1 User Manual UNO-3300G Series Intel® Core® i7/Celeron Processors Embedded Automation PC, with 2x PCI(e)/ PCI Extension Slots...
  • Page 2 No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. Information provided in this manual is intended to be accurate and reliable. How- ever, Advantech Co., Ltd.
  • Page 3 Because of Advantech’s high quality-control standards and rigorous testing, most of our customers never need to use our repair service. If an Advantech product is defec- tive, it will be repaired or replaced at no charge during the warranty period. For out- of-warranty repairs, you will be billed according to the cost of replacement materials, service time and freight.
  • Page 4 Technical Support and Assistance Visit the Advantech web site at http://support.advantech.com where you can find the latest information about the product. Contact your distributor, sales representative, or Advantech's customer service center for technical support if you need additional assistance. Please have the following information ready before you call: –...
  • Page 5 The sound pressure level at the operator's position according to IEC 704-1:1982 is no more than 70 dB (A). DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein.
  • Page 6 This product is intended to be supplied by a Listed Power Adapter or DC power source, rated 24Vdc, 4.2A minimum and Tma 55 degree C, if need further assis- tance, please contact Advantech for further information. Caution! Wiring minimum temperature 85 degree C.
  • Page 7 Il y a un risque d'explosion si la batterie est rem- placée de façon incorrecte. Remplacez uniquement avec le type identique ou équivalent recommandé par le fabricant. Jetez les piles usagées conformément aux instructions du fabricant. UNO-3300G Series User Manual...
  • Page 8 UNO-3300G Series User Manual viii...
  • Page 9: Table Of Contents

    SATA HDD Drive..................15 Figure 2.13SATA Mode Selection ..........15 Figure 2.14Detecting a RAID configuration ........ 16 Figure 2.15Creating a RAID Volume .......... 16 2.13 Audio Jack....................16 2.14 LED Indicators..................17 Chapter Initial Setup ........19 Connecting Power................... 20 UNO-3300G Series User Manual...
  • Page 10 Installing a Hard Disk ................22 Installing an Interface card..............23 Installing Power Cable ................24 Mounting UNO-3300G Series ..............25 Figure 3.2 Book mount .............. 25 Figure 3.3 Wall mount ............... 26 Figure 3.4 Detachable PC (Optional)_01 ........27 Figure 3.5 Detachable PC (Optional)_02 ........
  • Page 11: Chapter 1 Overview

    Chapter Overview This chapter provides an overview of UNO-3300G series' specifica- tions. Sections include:  Introduction  Hardware specification  Safety precautions  Chassis dimensions  Accessories...
  • Page 12: Introduction

    Introduction AAdvantech's UNO-3300G series offer an open and universal automation solution. The newest UNO-3300 series of the Control Cabinet PC have attractive and flexible extension capabilities such as 2 x USB2.0 & 2 x USB3.0 port, 1 x HDMI, 1 x DP, 1 x COM port, 2 x LAN ports, 2 x mPCIe. UNO-3384G also supports 1 x PCIex4 &...
  • Page 13: System Hardware

     Displays: 1 x HDMI, supports 1920 x 1200 @ 60 Hz 24 bpp; 1 x DP, supports  3200 x 2000 @ 60 Hz 24 bpp  Power Connector: 1 x 3 Pin, Terminal Block UNO-3300G Series User Manual...
  • Page 14: Environment

    Caution! Always ground yourself to remove any static electric charge before touching UNO-3000G series. Modern electronic devices are very sensi- tive to static electric charges. Use a grounding wrist strap at all times. Place all electronic components on a static-dissipative surface or in a static-shielded bag. UNO-3300G Series User Manual...
  • Page 15: Chassis Dimensions

    Chassis Dimensions Figure 1.1 UNO-3382G Dimensions Figure 1.2 UNO-3384G Dimensions Accessories Refer to the below accessories list for UNO-3300G series.  × 3-pin plug-in block for power wiring  × Warranty card UNO-3300G Series User Manual...
  • Page 16 UNO-3300G Series User Manual...
  • Page 17: Chapter 2 Hardware Functionality

    Chapter Hardware Functionality This chapter shows how to setup UNO-3300G series' hardware functions, including connecting peripherals, setting switches and indicators. Sections include:  Peripherals  RS-232 Interface  RS-422/485 Interface  LAN / Ethernet Connector  Power Connector  Mini PCIe Socket ...
  • Page 18: Introduction

    Introduction The following figures show the interfaces of UNO-3300 series and the detail informa- tion by each peripheral. Figure 2.1 UNO-3382G Dimensions Figure 2.2 UNO-3384G Dimensions UNO-3300G Series User Manual...
  • Page 19 Figure 2.3 UNO-3382G Bottom View Figure 2.4 UNO-3382G Front View Figure 2.5 UNO-3384G Bottom View Figure 2.6 UNO-3384G Front View UNO-3300G Series User Manual...
  • Page 20: Serial Interface (Com1)

    Serial Interface (Iso.COM) The UNO-3300G series offer one standard RS-232/422/485 serial communication interface ports: COM (Pin header CN35). The IRQ and I/O address of serial ports are listed as below. COM: 2E8, IRQ4 Figure 2.7 Pin header of COM1 2.2.1...
  • Page 21: To Switch The Internal Sw1/Sw2 According To The Placement

    2.2.2 To switch the internal SW1/SW2 according to the placement Figure 2.8 Location SW1: COM RS232/422/485 mode setting  Figure 2.9 Without termination UNO-3300G Series User Manual...
  • Page 22: Lan: Ethernet Connector

    USB EHCI, Rev. 2.0 compliant. The USB interface can be disabled in the system BIOS setup. Display Connector The UNO-3300G series provide a HDMI and DP controller for a high resolution inter- face. It supports up to full HD resolution for two independent displays. UNO-3300G Series User Manual...
  • Page 23: Rtc Battery

    User can set AT/ATX mode in BIOS setup menu “Chipset\Restore AC power loss”.  [Power ON]: AT mode  [Power OFF]: ATX mode Figure 2.11 AT/ATX adjustment Reset Button Press the “Reset” button to activate the hardware reset function. UNO-3300G Series User Manual...
  • Page 24: Pci Express Mini Card Socket

    Slot2 power PCI/PCIE card without FAN 3W (Note2) 3W (Note2) PCI card with FAN-on-card 6W (Note3) 6W (Note3) PCIE card with FAN-on-card 10W (Note3) 10W (Note3) PCI/PCIe Card need wide temperature (at least +70 ° C). UNO-3300G Series User Manual...
  • Page 25: Sata Hdd Drive

    20W power for slot1+slot2. 2.12 SATA HDD Drive The UNO-3300G series product supports two 2.5" SATA HDD with up to 6Gbps speed. The UNO-3300G support RAID0 and RAID1. The RAID function should be enabled in BIOS setup before you install an operating system into a RAID volume. User can enable RAID function in BIOS sub-menu “Advance\SATA Configuration”.
  • Page 26: Audio Jack

    Maximum Power is 5V / 700mA per SATA port. Hot-swappable function of HDD is in conflict with operation of RAID. 2.13 Audio Jack This product provides one Line-out port, one Line-in and one MIC (Pin Header). UNO-3300G Series User Manual...
  • Page 27: Led Indicators

    PWR: Green means norma, yellow is stand by.  HDD, Tx/Rx1: Flashing green means signals are being transmitted and received.  RTC: Red means RTC voltage low. R: reserved for end user, the 2 LED is Green. UNO-3300G Series User Manual...
  • Page 28 UNO-3300G Series User Manual...
  • Page 29: Chapter 3 Initial Setup

    Chapter Initial Setup This chapter introduces how to initialize UNO-3000G series. Sections include:  Chassis Grounding  Connecting Power  Connecting a Hard Disk  BIOS Setup and System Assign- ments...
  • Page 30: Connecting Power

    Connecting Power Connect one 24 VDC power source to an UNO-3300G series product. The power source can be from either a power adapter or an in-house power source. Figure 3.1 Power Connector Inserting an iDoor Module The UNO-3300 series have dual iDoor slots for various expansions. Follow the below exploded diagram to install iDoor modules into the system.
  • Page 31 Insert & lock the mini-PCI card using screws. Replacing the blanking plate with the iDoor plate. UNO-3300G Series User Manual...
  • Page 32: Installing A Hard Disk

    Installing a Hard Disk Follow the steps below to install a HDD/SSD into the system. Release thumb screw and pull up the HDD/SSD bracket. Screw the HDD/SSD to the bracket. UNO-3300G Series User Manual...
  • Page 33: Installing An Interface Card

    These backplanes provide PCIex4 and PCI slots to be compatible with different interface cards. Users can install interface cards based on their requirements. Follow the exploded diagram to install an interface card. Loosen the cover of the chassis. UNO-3300G Series User Manual...
  • Page 34: Installing Power Cable

    Insert your PCI/PCIe card and secure it. Replace the cover of the chassis. Installing Power Cable The UNO-3384G provides an internal backup power (24VDC output) on system board, External expansion cards or other devices that required additional power. UNO-3300G Series User Manual...
  • Page 35: Mounting Uno-3300G Series

    Mounting UNO-3300G Series The UNO-3300G series have unique design in two mounting types, Book mounting & Wall mounting. For these two convenient mounting types, which are easier to installa- tion without bracket. Below separate figures shows the capability of mounting: Figure 3.2 Book mount...
  • Page 36 Figure 3.3 Wall mount UNO-3300G Series User Manual...
  • Page 37 There is one specific application like as detachable PC, which allows quick assembly with display products. Figure 3.4 Detachable PC (Optional)_01 Figure 3.5 Detachable PC (Optional)_02 UNO-3300G Series User Manual...
  • Page 38 UNO-3300G Series User Manual...
  • Page 39: Appendix A System Settings And Pin Assignments

    Appendix System Settings and Pin Assignments...
  • Page 40: System I/O Address And Interrupt Assignment

    There are several connectors and switches on the inside board. The following sec- tions tell you how to configure the hardware setting. Figure A.01 & A.02 show the locations of the connectors and switches. Figure A.1 Bottom view of System board UNO-3300G Series User Manual...
  • Page 41: Function Of Connectors & Switches

    The connectors and switches on the inside boards are defined as table A.2 & A.3. Table A.2: Connectors on System board Label Function Power Switch Reset CN16 Audio CN20 Internal USB CN29 PCN1 24V Power Output External USB2.0+USB3.0 CN34 External USB2.0 CN36 HDMI CN14 CFast Mini PCIE Mini PCIE UNO-3300G Series User Manual...
  • Page 42: Audio (Pin Header)

    Label Function mSATA COM1 setting Reset Power input 18~36V RTC battery input Audio (Pin header) Table A.4: CN16 Audio Part Number 1655004510-01 Footprint WF_7x2P_79_BOX_RA_D Description Pin Name LOUTR LOUTL LOUT_JD LINR LINL LIN_JD MICR MICL MIC_JD UNO-3300G Series User Manual...
  • Page 43: Internal Usb

    Internal USB Table A.5: CN20 Internal USB Part Number 1655305020-01 Footprint WF_5P_79_BOX_D_721-81-05TW0 Description WAFER BOX 5P 2.00mm 180D(M) DIP 721-81-05TW80 Pin Name USB- USB+ Table A.6: CN35 COM1 Pin Name RTS# DSR# DTR#_RX- TXD_RX+ CTS# RXD_DATA+ DCD#_DATA- UNO-3300G Series User Manual...
  • Page 44: Lan1/Lan2

    RJ45_24P_RJ1402-88ND26R800 Description PHONE JACK RJ45 24P 90D(F) 1.27mm DIP RJ1402-88N Pin Name LAN1_MDI0+ LAN1_MDI0- LAN1_MDI1+ LAN1_MDI2+ LAN1_MDI2- LAN1_MDI1- LAN1_MDI3+ LAN1_MDI3- 3.3V LAN1LED_ACT# LAN1LED_LINK100 LAN1LED_LINK1000 LAN2_MDI0+ LAN2_MDI0- LAN2_MDI1+ LAN2_MDI2+ LAN2_MDI2- LAN2_MDI1- LAN2_MDI3+ LAN2_MDI3- 3.3V LAN2LED_ACT# LAN2LED_LINK100 LAN2LED_LINK1000 UNO-3300G Series User Manual...
  • Page 45: External Usb3.0

    External USB3.0 Table A.8: CN5 External USB3.0 Part Number 1654010969-01 Footprint USB_9x2P_UEA1112C-8HS6-4F Description Pin Name SSRX- SSRX+ SSTX- SSTX+ SSRX2- SSRX2+ SSTX2- SSTX2+ UNO-3300G Series User Manual...
  • Page 46: External Usb2.0

    External USB2.0 Table A.9: CN34 External USB2.0 Part Number 1654009513 Footprint USB_8P_UB1112C-8FDE-4F Description USB CONN. 8P 2.0mm 90D DIP UB1112C-8FDE-4F Pin Name UNO-3300G Series User Manual...
  • Page 47: Displayport

    A.10 DISPLAYPORT Table A.10: CN14 DISPLAYPORT Part Number 1654010437 Footprint DPCON_20P_3VD51203-H7JJ-7H Description Displayport Conn. 20P 0.5mm 90D(F) SMD 3VD51203- Pin Name config AUX+ AUX- +3.3V UNO-3300G Series User Manual...
  • Page 48: Hdmi

    A.11 HDMI Table A.11: CN36 HDMI Part Number 1654010203 Footprint HDMICON_21P_845-002-217CRL Description HDMI+DISPLAY Conn. 20P 90D(M) DIP 845-002-217CRL CLK+ CLK- UNO-3300G Series User Manual...
  • Page 49: Power Connector (Pwr)

    Table A.13: SW7 Power Switch Part Number 1600000049 Footprint SW-TP33WS83565 Description RESET SW ES-26A-K-T/R-H SMD 4p Pin Name PSIN Table A.14: SW8 Reset Part Number 1600002364 Footprint SW_2P_6-4-2_D Description PUSH SW ELTSA-62N-H 2P DIP 13.0x3.85mm Pin Name RESET# UNO-3300G Series User Manual...
  • Page 50 CFast 24P 1.27mm 90D(M) SMD N7G24-A0B2RA-10-0HT- Pin Name S1:GND S2:SATA TX+ S3:SATA TX- S4:GND S5:SATA RX- S6:SATA RX+ S7:GND PC1:NC PC2:GND PC3:NC PC4:NC PC5:NC PC6:NC PC7:NC PC8:PHYRDY PC9:HDDA PC10:NC PC11:NC PC12:NC PC13:+3.3V PC14:+3.3V PC15:GND PC16:GND PC17:NC UNO-3300G Series User Manual...
  • Page 51 Table A.16: CN6/CN7 Mini PCIE Part Number 1654006715 Footprint MINIPCIE_FULL_HALF_STANDARD Description Pin Name WAKE# +3.3VSB +1.5V UIM_PWR UIM_DATA REFCLK- UIM_CLK REFCLK+ UIM_RESET UIM_VPP PERST# PERn0 +3.3VSB PERp0 +1.5V SMB_CLK PETn0 SMB_DAT PETp0 USB D- USB D+ +3.3VSB +3.3VSB UNO-3300G Series User Manual...
  • Page 52 Table A.16: CN6/CN7 Mini PCIE +1.5V +3.3VSB Table A.17: : CN9 mSATA Part Number 1654006715 Footprint MINIPCIE_FULL_HALF_STANDARD Description Pin Name +3.3VSB +1.5V UNO-3300G Series User Manual...
  • Page 53 Table A.17: : CN9 mSATA SATA_RX+ +3.3VSB SATA_RX- +1.5V SMB_CLK SATA_TX- SMB_DAT SATA_TX+ +3.3VSB +3.3VSB +1.5V +3.3VSB Note! MINI1 (No Connection on pin 36/38) UNO-3300G Series User Manual...
  • Page 54: Power Input (Cn1)

    Table A.18: PCN1: reserve for power output, the voltage is same as power input (CN1) Part Number 1655304020 Footprint WF_4P_79_BOX_R1_D Description WAFER BOX 2.0mm 4P 180D(M) W/LOCK A2001WV2-4P Pin Name Note! This connector support max 2 A. UNO-3300G Series User Manual...
  • Page 55 UNO-3300G Series User Manual...
  • Page 56 No part of this publication may be reproduced in any form or by any means, electronic, photocopying, recording or otherwise, without prior written permis- sion of the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2016...
