- Page 3 • Receiver Specification and Port Description BEFORE USE Thank you for purchasing Graupner GR-8 HoTT 2.4GHz Receiver. This system is extremely versatile and may be used by beginners and pros alike. In order for you to make the best use of your system, please read this manual carefully.
- Page 4 Gyungki-Do KOREA 420-857 Phone: 82-70-7863-3674 Fax: 82-70-7863-3670 Customer Service E-mail: service@openhobby.com BOX CONTENTS GR-8 HoTT Receiver Manual Warranty Card Temperature/Voltage Sensor (S8362) WARNING NOTES • Never operate your car or truck in a crowded street with traffic. Especially, do not drive in a place near railway, chemical substance, gas to prevent any damage.
- Page 5 Use only genuine and matching Graupner/SJ connectors and accessory parts. • Make sure whenever you start connecting and operating the controller, that your transmitter is switched on, and has the throttle set to position “STOP”. Binding & RF Range Test BIND Press and hold Bind button for 3 sec while your receiver is powered on and then LED indicator is off.
- Page 6 1) Port 1, 2, 3, 4 should be connected to servo or ESC. 2) Port 5 supports low voltage warning alarm with beep and LED indicator. In addition, it is available to use with telemetry sensor. When using receiver battery (Nixx 4~5 cell, LiPo 2 cell), it needs to be connected to Port3. As for low voltage warning alarm, the default value is 3.7V.
- Page 7 • ENVIRONMENTAL PROTECTION NOTES...
- Page 8 This product must not be disposed of with other waste. Instead, it is the user’s responsibility to their waste equipment by handing it over to a designated collection point for the recycling of waste electrical and electronic equipment. The separate collection and recycling of your waste equipment at the time of disposal will help to conserve natural resources and ensure that it is recycled in a manner that protects human health and the environment.
