  • Page 1 Installation manual ENABLING BRIGHT OUTCOMES...
  • Page 2 Barco NV Beneluxpark 21, 8500 Kortrijk, Belgium www.barco.com/en/support www.barco.com Registered office: Barco NV President Kennedypark 35, 8500 Kortrijk, Belgium www.barco.com/en/support www.barco.com...
  • Page 3 Barco. Changes Barco provides this manual 'as is' without warranty of any kind, either expressed or implied, including but not limited to the implied warranties or merchantability and fitness for a particular purpose. Barco may make improvements and/or changes to the product(s) and/or the program(s) described in this publication at any time without notice.

  • Page 5: Table Of Contents

    Table of contents 1 Safety ........................................... 7 General considerations ..................................8 Risk Group 3 Safety ..................................10 1.2.1 General considerations............................10 1.2.2 High Brightness precautions: Hazard Distance ..................10 1.2.3 HD for fully enclosed projection systems.......................12 Important safety instructions..............................14 Product safety labels..................................18 Regulatory......................................19 Download Product Manual ................................20 2 Introduction........................................21 Installation requirements ................................22 Projector package overview..............................24...
  • Page 6 Boresight (Scheimpflug) adjustment............................53 6 G lens (0.37 - 0.4 : 1) UST 90° ..............................57 About the UST lens..................................58 Lens rotation mechanics................................59 Lens support installation ................................63 UST lens support adjustment..............................67 List of tools ........................................71 Index ..........................................73 R5916677 /00...

  • Page 7: Safety

    Ensure that you understand and follow all safety guidelines, safety instructions and warnings mentioned in this chapter before installing the G50 projector. Clarification of the term “G50” used in this document When referring in this document to the term “G50” means that the content is applicable for following Barco products: •...

  • Page 8: General Considerations

    • Before operating this equipment please read this manual thoroughly and retain it for future reference. • Installation and preliminary adjustments should be performed by qualified Barco personnel or by authorized Barco service dealers. • All warnings on the projector and in the documentation manuals should be adhered to.
  • Page 9 HIGH BRIGHTNESS PROJECTORS) in performing a task, and of measures to minimize the potential risk to themselves or other persons. Only Barco authorized SERVICE PERSONNEL, knowledgeable of such risks, are allowed to perform service functions inside the product enclosure. The term USER and OPERATOR refers to any person other than SERVICE PERSONNEL.

  • Page 10: Risk Group 3 Safety

    Safety 1.2 Risk Group 3 Safety 1.2.1 General considerations Notice on optical radiation from G50 Projector when it becomes Risk Group 3 • For RG3, no direct exposure to the beam shall be permitted. For RG3, operators shall control access to the beam within the hazard distance or install the product at a height that will prevent eye exposure within the hazard distance.
  • Page 11 Safety For example, projectors that have a HD greater than 1 m and emit light into an uncontrolled area where persons may be present should be positioned in accordance with “the fixed projector installation” parameters, resulting in a HD that does not extend into the audience area unless the beam is at least 2.0 meter above the floor level.

  • Page 12: Hd For Fully Enclosed Projection Systems

    The LIP shall be installed by Barco or by a trained and Barco-authorized installer or shall only be transferred to laser light show variance holders. This is applicable for dealers and distributors since they may need to install the LIP (demo install) and/or they transfer (sell, rent, lease) the LIP.
  • Page 13 Safety RESTRICTED AREA DIFFUSE REFLECTION Image 1–3 Restricted Access location (enclosed projection area). Restriction Zone. Projector. Projection Distance. Theater (observation area). Separation Width. Must be minimum 1 meter. For this type of setup 3 different HD shall be considered: • HD as discussed in “High Brightness precautions: Hazard Distance”, page 10, relevant for intrabeam...

  • Page 14: Important Safety Instructions

    (See chapter “Available lenses” in the installation manual), refer to chapter “Risk Group 3 Safety”, page for information regarding precautions. • FOR PROFESSIONAL USE ONLY means installation can only be carried out by Barco AUTHORIZED PERSONNEL familiar with potential hazards associated with high intensity light beams. R5916677 /00...
  • Page 15 Do not place flammable or combustible materials near the projector! • Barco large screen projection products are designed and manufactured to meet the most stringent safety regulations. This projector radiates heat on its external surfaces and from ventilation ducts during normal operation, which is both normal and safe.
  • Page 16 If the specified environmental conditions cannot be guaranteed (e.g., construction works), the projector must be removed, or switched off and fully protected until the requirements are fulfilled. • Contact Barco in case uncertainty exist on the environmental conditions linked to air contamination prior to install and operate the projector. •...
  • Page 17 Replacement parts: When replacement parts are required, be sure the service technician has used original Barco replacement parts or authorized replacement parts which have the same characteristics as the Barco original part. Unauthorized substitutions may result in degraded performance and reliability, fire, electric shock or other hazards.

  • Page 18: Product Safety Labels

    Safety 1.4 Product safety labels Light beam related safety labels Label image Label description FDA laser variance (US projectors only). This product is in conformity with performance standards fro laser products under 21 CFR 1040, except with respect to those characteristics aurhorized by Variance Number xxxx-x-xxxx effective on [effective date of variance approval].

  • Page 19: Regulatory

    Safety 1.5 Regulatory UK Compliance This product is fit for use in the UK. Authorised Representative: Barco UK Ltd Address: Building 329, Doncastle Road Bracknell RG12 8PE, Berkshire, United Kingdom R5916677 /00...

  • Page 20: Download Product Manual

    Safety 1.6 Download Product Manual Download Product Manual Product manuals and documentation are available online at www.barco.com/td. Registration may be required; follow the instructions given on the website. IMPORTANT! Read Installation Instructions before connecting equipment to the mains power supply.

  • Page 21: Introduction

    Introduction Installation requirements .......................22 Projector package overview......................24 Main unit ............................25 Input/Output ports.........................26 Control panel..........................27 Remote Control Unit ........................28 Lenses............................29 R5916677 /00...

  • Page 22: Installation Requirements

    Introduction 2.1 Installation requirements Environment conditions Table below summarizes the physical environment in which the G50 projector may be safely operated or stored. Operating Non-Operating Environment Ambient Temperature 5°C (41°F) to 40°C (104°F) -10°C (14°F) to 60°C (140°F) Humidity 10% to 85% RH Non-Condensed...
  • Page 23 Contact Barco in case uncertainty exist on the environmental conditions linked to air contamination prior to install and operate the projector. Main power requirements The G50 projector operates from a nominal mono phase power net with a separate earth ground PE. Projector Power requirements...

  • Page 24: Projector Package Overview

    The product Safety Manual and Quick Start Guide are also included. Download the complete and latest updated installation manual and user guide form the Barco website. The projection lens is an optional item, not a standard accessary in the package.

  • Page 25: Main Unit

    Introduction 2.3 Main unit Component locations Image 2–5 IR receiver (top) IR receiver (front) LED status indicators Projeciton lens Right speaker Image 2–6 Input/Output panel Control panel Adjustable feet Power switch and socket Rear speaker Airflow Image 2–7 R5916677 /00...

  • Page 26: Input/Output Ports

    Introduction 2.4 Input/Output ports Input/Output ports 12 13 HDBaseT ETHERNET DISPLAY PORT HDMI-2 IN HDMI-1 IN HDMI OUT AUDIO Out 12V Out REMOTE 3D SYNC 3D SYNC RS232 (5V/1.5A) DC 12V output HDMI input port 1 3D sync output port Wired remote input HDMI output port USB port type A...

  • Page 27: Control Panel

    Introduction 2.5 Control panel Control panel Adjust lens position Confirm the settings Adjust the image focus Menu navigation buttons Adjust horizontal/vertical keystone Back to parent menu or exit menu ZOOM FOCUS Enter OSD menu Power On/Off Adjust the image size R5916677 /00...

  • Page 28: Remote Control Unit

    Introduction 2.6 Remote Control Unit Remote Control Unit (RCU) Power On Power Off (Standby) Number keys 0-9 Source information Projector ID setting Auto sync input source Select input source Confirm menu selection Menu navigation Adjust brightness Adjust contrast Open OSD menu Back to parent menu or exit menu Preset color mode Display test patterns...

  • Page 29: Lenses

    2.60 5.03 5.00 9.36 1.21 1.94 1.26 1.46 1.45 1.85 1.84 2.38 2.35 2.95 2.94 5.66 5.61 10.51 This lens is sold as a package containing lens, lens support and safety cable (see Barco website for ordering information) R5916677 /00...
  • Page 30 Introduction R9802300 R9801840 R9832755 R9801784 R9832756 R9832778 Projection Lens Short Short Ultra Long Long Zoom Wide Zoom Standard Throw Throw Zoom 1.35 2.15 1.40 1.63 1.61 2.05 2.05 2.64 2.62 3.28 3.27 6.30 6.21 11.67 1.48 2.37 1.55 1.79 1.78 2.26 2.26 2.91...

  • Page 31: Installation Procedures

    Installation procedures RCU battery installation ........................32 Installing the lens..........................33 Installing the lens safety cable .......................34 Connecting the projector with the power net..................38 Connecting to a computer or laptop....................39 Connecting to video sources......................40 Ceiling mount installation ......................41 Software update ...........................42 To install the UST lens see chapter “G lens (0.37 - 0.4 : 1) UST 90°”, page 57, and to install the UST 90°...

  • Page 32: Rcu Battery Installation

    Installation procedures 3.1 RCU battery installation How to install the batteries of the Remote Control Unit Remove the cover by sliding it in the direction indicated by the arrow Insert two new AAA (alkaline) batteries (observe the polarity). Note: Batteries are not delivered with the RCU! Replace the cover.

  • Page 33: Installing The Lens

    Installation procedures 3.2 Installing the lens WARNING: This procedure may only be performed by qualified technical service personnel. How to install the lens Remove the lens cap counterclockwise. Caution: Lens cap should be removed before installing the lens. If not it will damage the projector. Gently insert the lens in the lens holder.

  • Page 34: Installing The Lens Safety Cable

    Installation procedures 3.3 Installing the lens safety cable When to use the lens safety cable The lens safety cable must be used in any circumstance where the projector is mounted above people. Do this to secure the mounted lens in the lens holder. Content of the lens safety cable kit (R9801196) •...
  • Page 35 Installation procedures Image 3–4 Image 3–5 Snap the first loop end of the safety cable into one of the following clips and let the loop end point downwards. 1. Configuration A: Use the upper clip on the side of the cable bundle (reference 2, Image 3–4).
  • Page 36 Installation procedures Image 3–7 Example of Configuration A Image 3–8 Example of Configuration B Close the U-bolt and tighten it. Note: Make sure the safety cable is tightened around the lens before tightening the U-bolt nuts. Place the shackle through the free loop end of the safety cable. Connect the shackle on the truss or rigging frame.
  • Page 37 Installation procedures Image 3–11 Carefully slide the safety cable through the cable clips. Make sure the cable is placed between the motor block and the cover plate. Slide the cable through the loop end at the beginning of the cable. Mount a U-bolt on the cable, with the open ends oriented outwards (reference 3, Image 3–11).

  • Page 38: Connecting The Projector With The Power Net

    Installation procedures 3.4 Connecting the projector with the power net CAUTION: Use only the power cord provided with the projector. CAUTION: Ensure that the power net meets the power requirements of the projector. How to connect with the power net Ensure that the power switch stands in the '0' (OFF) position (reference 1).

  • Page 39: Connecting To A Computer Or Laptop

    Installation procedures 3.5 Connecting to a computer or laptop Wiring diagram Camcorder Monitor Desktop Laptop Speakers HDBaseT ETHERNET DISPLAY PORT HDMI-2 IN HDMI-1 IN HDMI OUT AUDIO Out 12V Out REMOTE 3D SYNC 3D SYNC RS232 (5V/1.5A) Image 3–14 3D Sync cable DisplayPort cable 3D Sync cable USB cable...

  • Page 40: Connecting To Video Sources

    Installation procedures 3.6 Connecting to video sources Wiring diagram Video cassette recorder DVD Player Component video output equipment DISPLAY PORT HDBaseT ETHERNET HDMI-2 IN HDMI-1 IN HDMI OUT AUDIO Out 12V Out REMOTE 3D SYNC 3D SYNC RS232 (5V/1.5A) Image 3–15 HDMI cable HDMI cable The diagram shows the cables/connectors that may be used to connect to various devices.

  • Page 41: Ceiling Mount Installation

    Installation procedures 3.7 Ceiling mount installation Requirements To prevent damage to your projector, please use a Barco recommended ceiling mount. Ensure the screws used to install the mount to the projector meet the following specifications: • Screws: M4 x 10 (four pieces) •...

  • Page 42: Software Update

    How to update the software using the web interface. Power on the projector. Download the latest firmware file ( format .iso) from Barco's website. The firmware can be downloaded for free from Barco's website, (URL: http://www.barco.com). Click on myBarco and log in to get access to secured information.
  • Page 43 Installation procedures Image 3–18 Example of the upgrade page Browse to the desired update package (format .iso) and confirm (reference 2). Click Upgrade (reference 3) to start the upgrade process. The update file will be transferred to the projector and installed. The projector will reboot when completed. Take note that the update process can take a long time to complete.
  • Page 44 Installation procedures R5916677 /00...

  • Page 45: Powering On/Off The Projector

    Powering On/Off the projector Powering On the projector ......................46 Power off the projector ........................48 This chapter assumes that the power cord and (all) signal cables are securely connected. For detailed instructions see installation manual. R5916677 /00...

  • Page 46: Powering On The Projector

    Is this the first time that the projector starts up? (First installation or after a factory reset) ► If yes, a popup window appears with the request to accept Barco’s End User License Agreement (EULA). Select CONTINUE to accept the EULA terms and to proceed using the projector. If you do not accept the EULA terms (CANCEL), the projector will be switched off.
  • Page 47 Powering On/Off the projector WARNING: Do not look directly into the lens when the projector is on. The strong light may cause permanent eye damage. R5916677 /00...

  • Page 48: Power Off The Projector

    Powering On/Off the projector 4.2 Power off the projector How to power off the projector Press the Standby button (reference 2) on the remote control or the Power On/Off button (reference 3) on the control panel. ZOOM Image 4–4 A confirmation request will be prompted on the screen. Press the same button again to confirm.

  • Page 49: Adjusting The Projected Image

    Adjusting the projected image Adjusting the projector’s position....................50 Adjusting the lens offset ........................51 Boresight (Scheimpflug) adjustment....................53 R5916677 /00...

  • Page 50: Adjusting The Projector's Position

    Adjusting the projected image 5.1 Adjusting the projector’s position Positioning the projector To determine where to position the projector, consider the size and shape of your screen, the location of your power outlets, and the distance between the projector and the rest of your equipment. Here are some general guidelines: •...

  • Page 51: Adjusting The Lens Offset

    Adjusting the lens position to determine the image position on the screen. The veritcal lens offset (shift) range for G50 projector is +/-50%, and the horizontal lens offset (shift) range is +/-15%. The offset range is calculated in accordance with industry standards, with which the image offset is calculated by full image size.
  • Page 52 Adjusting the projected image Horizontal Image Offset: +/-20% -20% +20% 100% Image 5–4 R5916677 /00...

  • Page 53: Boresight (Scheimpflug) Adjustment

    Adjusting the projected image 5.3 Boresight (Scheimpflug) adjustment What is Boresight (Scheimpflug) The lens holder has to be adjusted so that the “sharp focus plane” of the projected image falls together with the plane of the screen (Fp1→Fp2). This is achieved by changing the distance between the DMD plane and the lens plane (Lp1→Lp2).
  • Page 54 Adjusting the projected image Fixed ring Floating ring • Manual adjust the floating ring before adjust Zoom & Focus for better optical performance. • Scale on floating ring shows the projection distance. • The projection distance is from projector lens to screen. Example: When the distance between screen and projector lens is 1.4 meter, adjust floating ring scale to “1.40”...
  • Page 55 Adjusting the projected image Image 5–8 Note: This process may cause the other areas of the image to slide out of focus. This is totally normal. If zone H is in focus on the screen, please check the focal plane of zone I. •...
  • Page 56 Adjusting the projected image R5916677 /00...

  • Page 57: Lens (0.37 - 0.4 : 1) Ust 90

    G lens (0.37 - 0.4 : 1) UST 90° About the UST lens........................58 Lens rotation mechanics .......................59 Lens support installation........................63 UST lens support adjustment......................67 UST 90° sales kit The sales kit contains: • The UST lens • The UST lens support •...

  • Page 58: About The Ust Lens

    Possible mounting positions This lens can be mounted on the G50 series of projectors and can be mounted in two positions: facing upwards and to the left. The motor housing must be turned to the correct position before the lens is mounted in the projector.

  • Page 59: Lens Rotation Mechanics

    G lens (0.37 - 0.4 : 1) UST 90° 6.2 Lens rotation mechanics Overview The Lens body can be rotated against the Interface unit when eight M3 cap screws are removed. It can be refastened to the Interface unit in increments of 90°. Image 6–2 Lens body Interface unit...
  • Page 60 G lens (0.37 - 0.4 : 1) UST 90° Image 6–4 Left mark on the lens For left projection, make sure the red dot on the interface is next to the “Left” marking on the lens. Image 6–5 Wire routing Projection orientation : left 90°...
  • Page 61 G lens (0.37 - 0.4 : 1) UST 90° Image 6–6 90° rotated position wire clamper PCBA module Image 6–7 Up mark on the lens R5916677 /00...
  • Page 62 G lens (0.37 - 0.4 : 1) UST 90° Image 6–8 Wire routing Projection orientation : Up R5916677 /00...

  • Page 63: Lens Support Installation

    G lens (0.37 - 0.4 : 1) UST 90° 6.3 Lens support installation Components Image Description Quantity Beam Base plate Lens holder module Lens clamp module Safety bar Socket head screw M6x12 Socket head screw M6x22 Spring washer M6 Washer M6 Socket head screw M4x10 Required tools...
  • Page 64 G lens (0.37 - 0.4 : 1) UST 90° Image 6–9 Mount the base plate on the projector beams. Use 4 bolts M6x22 with 4 spring washers M6 and 4 washers M6 (reference 1 in Image 6–10). Insert the spring washer in between the screw head and the washer. Tighten with a torque between 3.5 and 9.8 Nm When the projector will be used in table mounting configuration, also turn in the four feet (reference 2 in drawing B).
  • Page 65 G lens (0.37 - 0.4 : 1) UST 90° Fixate the adapter plate with 3 screws M4x10 to the lens. To continue, go to step 8. Image 6–13 Image 6–14 For up projection: adapt the lens clamp module. Remove the lens clamp part from the lens clamp module by removing the 3 screws (Image 6–15.
  • Page 66 G lens (0.37 - 0.4 : 1) UST 90° Image 6–18 Mount a safety cable through the eye on the safety bar. Slide the safety cable through the eye (reference 1 on Image 6–19) on the safety bar (reference 2 on Image 6–19) and then through the loop end at the beginning of the cable (reference 1 on Image...

  • Page 67: Ust Lens Support Adjustment

    6.4 UST lens support adjustment About lens detection G50 will detect the UST lens type while inserting the lens or reboot the projector. The image will automatically flipped as default and the lens memory function will be automatically disabled. For any type of projector, do not use the memory recall functionality.
  • Page 68 G lens (0.37 - 0.4 : 1) UST 90° Fine-tune the tilt of the projected image, using screw 5. Using this method, you can adjust ±7.5°. Image 6–23 Tip: Turning screw 5 clockwise will tilt the image counterclockwise. Turning the screws counterclockwise will tilt the image clockwise.
  • Page 69 G lens (0.37 - 0.4 : 1) UST 90° Image 6–25 Note: Screws 2 & 3 are tightened but lens can be pushed softly up or down to observe the image quality variation. Is the horizontal resolution/unbalance acceptable when comparing between region C and D. •...
  • Page 70 G lens (0.37 - 0.4 : 1) UST 90° CAUTION: Do not execute any lens movements when the UST lens is fixed in the Lens Support. R5916677 /00...

  • Page 71: List Of Tools

    List of tools Allen wrench 3 mm Allen wrench 4 mm Allen wrench 5 mm Boresight extenders Boresight L shape socket tool R5916677 /00...
  • Page 72 List of tools R5916677 /00...

  • Page 73: Index

    Index Adjustments 49 Hazard Distance 10, 12 Hazardous Chemicals 17 High Brightness precautions 10 Boresight Adjustment 53 Box content 24 I/O ports 26 Install Lens 33 UST 90° 57 Installation 31 Ceiling mount 41 Installation Requirements 22 Connections Introduction 21 Computer 39 Laptop 39 Video sources 40...
  • Page 74 Index Adjustment 67 G lens (0.37 - 0.4 : 1) UST 90° 63 Notice on safety 8 R9801830 63 R9801830 Rotation mechanics 59 On/Off 45 Personal injury 14 Position 50 Power 45 Off 48 Power cord 38 Power On 46 Projector damage 15 RCU 28 Battery 32...
  • Page 76 R5916677 /00 | 2023-06-28 www.barco.com...
