1.

HOW TO CONFIGURE INTERNET CONNECTION

EU-WiFi 8S p has a built-in Internet module, which enables the user to control the heating system via the Internet. First,
connect to the Internet by selecting your WiFi network in the menu: <WiFi network selection>. Such parameters as IP
Address, IP Mask, Gate Address may be set manually or it is possible to activate DHCP option (enabled by default).
Next, go to https://emodul.eu/ and create your account. After selecting <Registration> in the controller menu, the system
generates a code which must be entered in <Settings> tab of the emodul.eu website (Register module).
2.

HOW TO CONFIGURE THE EXTERNAL SENSOR EU-C-8ZR

It is necessary to register the external sensor by selecting <Registration> in the EU-WiFi 8S p controller ( Main menu >
External sensor > Registration) and pressing the communication button on the external sensor (press the button briefly
once).
The registration process enables the external sensor automatically. Once registered, the sensor may be switched off at
any time by selecting <OFF> .
NOTE
Switching the sensor off in the external sensor menu only interrupts the communication (the external
temperature is no longer displayed on the external controller screen). It does not disable the external sensor
itself – it remains active until the battery is flat.
3. HOW TO CONFIGURE TEMPERATURE SENSORS AND R OOM REGULATORS
To enable EU-WiFi 8S p to control a given zone, it is necessary to provide it with current temperature value. The easiest
way is to use the EU-C-8r temperature sensor. If the user wants to be able to change the pre-set temperature value
directly from the zone, it is advisable to use EU-R-8b , EU-R-8bw or EU-R-8z room regulator. Regardless of the type of
temperature sensor / room regulator chosen, it must be registered in a particular zone in the EU-WiFi 8S p controller
menu.
In order to register the sensor/room regulator, go to the submenu of a given zone and select Registration
(Zone/Registration). Next, press the communication button which can be found on the back of the selected temperature
sensor/room regulator (in the case of EU-C-8r, EU-R-8b, EU-R-8bw, EU-R-8z, press the button once briefly). If the process
has been completed successfully, the EU-WiFi 8S p controller display will show an appropriate message. Otherwise, the
process must be conducted again.
control light
9
channel change
button
