EVAL-ADUCM331QSPZ User Guide
KEIL μVISION5 INTEGRATED DEVELOPMENT ENVIRONMENT
INTRODUCTION
The Keil μVision5 integrated development environment (IDE)
integrates all the tools necessary to edit, assemble, and debug
code. The
ADuCM330/ADuCM331
supports nonintrusive emulation limited to 32 kB code. This
section describes the project setup steps to download and debug
code on an
ADuCM330/ADuCM331
recommended to use the J-Link debugger driver.
QUICK START STEPS
Starting μVision5
First, ensure that the CMSIS pack for the
has been installed (see the Getting Started section).
After installing Keil μVision5, a shortcut appears on the PC
desktop. Double-click the shortcut to open Keil μVision5.
Figure 5. Keil μVision5 Desktop Shortcut
1.
When Keil opens, click the Pack Installer button on the
toolbar.
Figure 6. Pack Installer Button
2.
The Pack Installer window opens.
Figure 7. Pack Installer Window
development system
development system. It is
ADuCM330/ADuCM331
Rev. 0 | Page 5 of 6
3.
Install the CMSIS pack. In the Pack Installer window, click
File > Import and locate the downloaded CMSIS pack.
Follow the on-screen prompts to install.
4.
In the right-hand side of the window, under the Devices
tab, click Analog Devices > ADuCM33x Series >
ADuCM330.
Figure 8. Devices Tab
5.
In the left-hand side of the window, click the Examples tab.
Figure 9. Examples Tab
6.
Select the Blinky example and click copy.
7.
Choose a destination folder and click ok. This installs the
Blinky example and necessary startup files to your PC.
Figure 10. Blinky Example
UG-718
