Chapter 1: Product Introduction
Network
▪ Intel FOXVILLE
▪ 2 x RJ45 connector with LEDs at back panel*
– 1 x RJ45 from Intel I225-LM GbE controller,
support Intel Active Management Technology 11.0
®
– 1 x RJ45 from Intel ® I225-V GbE controller
– Support PXE LAN boot ROM for Ethernet Boot up
– Support WOL
To fully support speeds of up to 2.5GbE, only CAT6A shielded cable
is recommended.
Power Supply
▪ 1 x External 12V/10A 120W DC input power adapter with lock
Environment
▪ Operating Temperatures: @ 100% CPU loading and component thermal
profile : 0~60 °C
▪ Storage Temperature: -40°C ~80°C
▪ Humidity: 95% (non-condensing)
Dimensions
▪ 183mm (L) x 140mm (W) x 48mm (H)
Operating System
▪ Windows 10 64-bit
▪ Windows 11 Enterprise or LTSC (64-bit) -Evaluation version
▪ Linux 64-bit
