The end of the instrument opposite the shackle houses the sensor payload which is
mechanically protected by a cage. The AML-3 utilizes a thread-on sensor cage, and the
AML-6 utilizes a bolted-on sensor cage. In some configurations the cage may be different
lengths depending on the sensors installed (AML-3 only) or made from a copper alloy to prevent
biofouling (AML-6 only). The default cage for both instruments uses stainless steel.
Typical specifications of an AML LGR are described in the table below.
Specifications:
Model 500m Variants (AML-3 or AML-6)
Depth rating 500 meters [1640 feet]
Material AML-3: Acetal pressure case
AML-6: Acetal pressure case
GPS Capability Yes
Data storage 30 GB
Software Sailfish
Communication USB-C
WiFi
Maximum 20 Hz
Sample Rate
Note: Sampling by pressure or
sound velocity increment is also
available.
Power AML-3:
4 cell rechargeable internal battery
45Wh capacity (expected battery
life ~12 hours)
AML-6:
8 cell rechargeable internal battery
95Wh capacity (expected battery
life ~24 hours)
PC or wall charging over USB
(10W minimum)
Note: USB ports of some PC and
laptops may not meet the minimum
charging requirement of the
instrument. It is recommended to
AML Oceanographic Ltd.
6000m Variants (AML-3 or AML-6)
6000 meters [19685 feet]
AML-3: Titanium pressure case
AML-6: Acetal pressure case with
internal metal reinforcement
No
30 GB
Sailfish
USB-C
20 Hz
Note: Sampling by pressure or
sound velocity increment is also
available.
AML-3:
4 cell rechargeable internal battery
45Wh capacity for the AML-3
(expected battery life ~12 hours)
AML-6:
8 cell rechargeable internal battery
95Wh capacity (expected battery life
~24 hours)
PC or wall charging over USB (10W
minimum)
Note: USB ports of some PC and
laptops may not meet the minimum
charging requirement of the
instrument. It is recommended to
