Instrument Specifications
Max Depth
Operating Range
Weight (Air)
Weight (Water)
Battery Capacity
¹
WiFi
USB
Depth Rating
WARNING
Every AML instrument and sensor
is rated to a maximum deployment
depth. The maximum depth rating is
always indicated clearly on the
outside of the pressure housing.
Never deploy a system beyond the
shallowest depth rating indicated
amongst the instrument and installed
sensors. Never deploy an instrument
with any sensor or charging ports
exposed.
For more info please visit AMLoceanographic.com or call +1 250 656 0771
500 m
6000 m
-5 to 45 °C
1.36 kg
2.5 kg
0.7 kg
1.9 kg
14 h (operating)
18 h (standby)
²
Rechargable
GPS
Ports
AML-3
Quick Start
Guide
Charge The Battery
1. Remove the protective cap* from the
USB charging bulkhead (Figure 1).
2. Use the USB charging cable and AC
adapter to connect the instrument to
AC power.
3. The instrument will begin charging
automatically.
Figure 1
*Remove the protective cap in clean dry
conditions ONLY. Without the protective cap,
the USB connector is NOT splash-proof.
LGR
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for AML Oceanographic AML-3 LGR
Summary of Contents for AML Oceanographic AML-3 LGR
- Page 1 AML-3 Instrument Specifications Max Depth 500 m 6000 m Quick Start Operating Range -5 to 45 °C Guide Weight (Air) 1.36 kg 2.5 kg Weight (Water) 0.7 kg 1.9 kg 14 h (operating) Battery Capacity 18 h (standby) Charge The Battery 1.
- Page 2 Connect With Sailfish¹ LED Indicator Legend 1. Install Sailfish on a Windows PC from Ready, GPS Locked ² either: Ready, GPS Acquiring ³ - USB drive Logging - AMLoceanographic.com/software Ready, Battery Low, GPS Locked ² You may be prompted to select Ready, Battery Low, GPS Acquiring ³...
