X2Change™ Sensors - AML Oceanographic AML-3 User Manual

cage in place (not the 6 installed on the pressure housing) and slide it off the pressure housing.
Note: It is very important that the screws installed on the pressure housing are not removed.
Performing this operation without AML authorization will void the warranty and may damage the
instrument.
8.2 X2Change™ Sensors
X2Change™ sensors are installed on the AML-3 or AML-6 sensor end cap. There are 3 sensor
ports available on the AML-3 and 6 sensor ports available on the AML-6 (and 1 port for an
optional UV Antifouling system). Sensors are installed or removed by hand with no special tools
required. Most combinations of X2Change™ sensors are permitted ( See notes on installing
sensors ). The image below is the depiction of an AML-6 sensor end cap with the optional UV
Antifouling port.
AML Oceanographic Ltd. 38 / 43
