UM-D-005
DA14AVDDECTDEVKT Quick Start Guide

Figure 2: Segger J-Link Lite and 20-to-10 Pin Adapter with Cable

Table 1: Contents of the DA14AVDDECTDEVKT Box

DA14AVDDECTDEVKT
Carrier Boards
MiniUSB Cable
ARM debugger (Segger J-Link LITE) with ARM JTAG-20-10
adapter
Paper insert (for out-of-the-box use)
3.2

Prerequisites

●
Experience with the C programming language.
●
Experience with development of embedded systems.
●
Experience with Eclipse (Dialog's Smartbeat
3.3

Powering Options

The carrier boards can be powered in two ways:
●

Powering via USB

●
Power via Battery (Li-Ion or NiMH)
Default jumper settings are marked by white rectangles on the PCB and jumper settings are the
same for J203, J201, and J4
carrier boards are shipped with the default jumper settings.
3.3.1 Powering via USB
To power the carrier boards via USB, connect your PC to the miniUSB connector named "USB" on
the carrier boards (marked blue in
(marked with red on Figure 3
User Manual
CFR0012
TM
AVD Studio) provides an advantage.
(Figure 3) when the board is powered from USB or Li-Ion battery. The
Figure 3). Use the default jumper settings for J203, J201, and J4
and also Figure 4 for zoomed image).
Revision 1.2
6 of 22
Included in the Box
2 ×
3 ×
1 ×
1 ×
18-Jan-2021
