DA14535
SMARTBOND TINY™ MODULE Development Kit
This document outlines the system design, configuration options and supported features of DA14535
SMARTBOND TINY™ MODULE Development Kit, PCB version 610-06-A.
Contents
1.
References ...................................................................................................................................................... 3
2.
Introduction ..................................................................................................................................................... 4
2.1
Features of DA14535 SMARTBOND TINY™ MODULE DB ................................................................... 5
2.2
Features of DA1453x Pro-MB ................................................................................................................. 6
2.3
Features of PMM2 (Power Measurement Module, 500-29-x) ................................................................. 6
3.
Get Started with DA14535 SMARTBOND TINY™ MODULE Development Kit .......................................... 7
3.1
DA14535MOD ......................................................................................................................................... 7
3.2
Hardware Components of the DEVKIT ................................................................................................... 7
3.3
First Steps with DA14535 SMARTBOND TINY™ MODULE DEVKIT .................................................... 8
3.3.1
DA14535 SMARTBOND TINY™ MODULE Development Kit Pro Setup ................................ 8
4.
DA14535 SMARTBOND TINY™ MODULE Daughterboard ....................................................................... 11
4.1
GPIOs and Pin Assignment on DA14535 SMARTBOND TINY™ MODULE DB .................................. 13
4.2
Power Section ....................................................................................................................................... 16
4.2.1
Default Power Supply Option Configuration .......................................................................... 16
4.2.2
Optional USB Power Section ................................................................................................. 16
4.3
Reset Operation .................................................................................................................................... 17
4.4
General Purpose Buttons ...................................................................................................................... 18
4.5
General Purpose LEDs ......................................................................................................................... 19
4.6
MikroBUS™ Module .............................................................................................................................. 20
4.7
Debugging Interface .............................................................................................................................. 21
4.8
Programming and Debugging Interface Setup ...................................................................................... 22
4.8.1
1-wire UART, JTAG, RESET ................................................................................................. 23
4.8.2
2-wire UART, JTAG, RESET ................................................................................................. 25
4.8.3
4-wire UART, JTAG, RESET ................................................................................................. 26
5.
Known Issues................................................................................................................................................ 27
5.1
Keil JTAG Default Clock Speed ............................................................................................................ 27
Appendix A DA14535 SMARTBOND TINY™ MODULE DB [610-06-A] ............................................................ 28
A.1
Schematic .............................................................................................................................................. 28
A.2
Placed Components .............................................................................................................................. 29
6.
Revision History ........................................................................................................................................... 30
UM-B-173 Revision 1.1
July 22, 2024
CFR0012
User Manual
Page 1
Advertisement
Table of Contents
Related Manuals for Renesas SMARTBOND TINY DA14535
Summary of Contents for Renesas SMARTBOND TINY DA14535
-
Page 1: Table Of Contents
User Manual DA14535 SMARTBOND TINY™ MODULE Development Kit This document outlines the system design, configuration options and supported features of DA14535 SMARTBOND TINY™ MODULE Development Kit, PCB version 610-06-A. Contents References ..............................3 Introduction ..............................4 Features of DA14535 SMARTBOND TINY™ MODULE DB ..............5 Features of DA1453x Pro-MB ......................... - Page 2 DA14535 SMARTBOND TINY™ MODULE Development Kit Hardware Figures Figure 1. DA14535 SMARTBOND TINY™ MODULE ....................4 Figure 2. DA14535 SMARTBOND TINY™ MODULE DEVKIT ................4 Figure 3. DA14535 (right) and DA14531 (left) SMARTBOND TINY™ MODULE DB ..........5 Figure 4. Hardware system of DA14535MOD ......................7 Figure 5.
-
Page 3: Terms And Definitions
DA14531, Datasheet, Renesas Electronics. DA14535, Datasheet, Renesas Electronics. UM-B-114, DA14531 Devkit Pro Hardware, User Manual, Renesas Electronics. UM-B-141, DA14531- SMARTBOND TINY™ MODULE Development Kit Hardware, User Manual, Renesas Electronics. UM-B-169, DA1453x Hardware Pro Development Kit, Renesas Electronics. UM-B-159, DA14535 Module Getting Started Guide, Renesas Electronics. -
Page 4: Introduction
DA14535 SMARTBOND TINY™ MODULE Development Kit Hardware 2. Introduction This document describes the development kit of the DA14535 SMARTBOND TINY™ MODULE (DA14535MOD). Figure 1. DA14535 SMARTBOND TINY™ MODULE DA14535 SMARTBOND TINY™ MODULE development kit is implemented on a Daughterboard (DB) (610-06-A) and it comes with DA1453x Pro-MB (610-01-B) and PMM2 (500-29-E), Figure DA14531 SMARTBOND TINY™... -
Page 5: Features Of Da14535 Smartbond Tiny™ Module Db
DA1453x Pro-MB (610-01-B). DA1453x Pro-MB (610-01-B) and PMM2 (500-29-E) are thoroughly analyzed in Ref. [7]. Features of DA14535 SMARTBOND TINY™ MODULE DB ▪ Integrated Renesas DA14535 SMARTBOND TINY™ MODULE ▪ Different reference numbers for the two Modules, 610-06-A for DA14535MOD ▪ Reset push button (SW3) ▪... -
Page 6: Features Of Da1453X Pro-Mb
DA14535 SMARTBOND TINY™ MODULE Development Kit Hardware Features of DA1453x Pro-MB ▪ A slot to connect a DA1453x Pro-DB which hosts one of the: • DA14535MOD, DA14535 SMARTBOND TINY™ MODULE • DA14531MOD, DA14531 SMARTBOND TINY™ MODULE • DA14531-WLCSP17 • DA14533- FCQFN22 •... -
Page 7: Get Started With Da14535 Smartbond Tiny™ Module Development Kit
Renesas SmartBoot, preloaded on the SPI data flash. Renesas SmartBoot is a secondary bootloader that can be used to add functionality to the boot sequence of DA14535MOD. The features added by the SmartBoot bootloader include two wire UART booting (on GPIOs P0_5, P0_6) and enabling Software Updates over the Air (SUotA), see Ref. -
Page 8: First Steps With Da14535 Smartbond Tiny™ Module Devkit
DA14535 SMARTBOND TINY™ MODULE Development Kit Hardware Figure 5. Mount DA14535 SMARTBOND TINY™ MODULE DB to DA1453x Pro-MB with PMM2 First Steps with DA14535 SMARTBOND TINY™ MODULE DEVKIT The DA1453x Pro-MB, as well as DA14535 SMARTBOND TINY™ MODULE DB, come with a pre- defined default configuration. -
Page 9: Figure 6. Da1453X Pro-Mb Default Jumper Configuration With Da1453X Smartbond Tiny™ Module Db Attached
DA14535 SMARTBOND TINY™ MODULE Development Kit Hardware Figure 6. DA1453x Pro-MB default jumper configuration with DA1453x SMARTBOND TINY™ MODULE DB attached UM-B-173 Revision 1.1 Page 9 July 22, 2024 CFR0012... -
Page 10: Table 2. Da1453X Pro-Mb Default Jumper Settings
DA14535 SMARTBOND TINY™ MODULE Development Kit Hardware Table 2. DA1453x Pro-MB default jumper settings Function Jumper settings Element number J1:1-2, not mounted, J1:3-4, not mounted, SPI Data Flash (U2) located on DA1453x J15-6, not mounted, Pro-MB is disconnected. J1:7-8, not mounted, J1:9-10 not mounted. -
Page 11: Da14535 Smartbond Tiny™ Module Daughterboard
DA14535 SMARTBOND TINY™ MODULE Development Kit Hardware 4. DA14535 SMARTBOND TINY™ MODULE Daughterboard The system on DA14535 SMARTBOND TINY™ Daughterboard (DB) consists of the DA14535 Module, the power section, the general purpose LEDs and Buttons, the debugging connector and the MikroBUS™ section. 7, and the actual component’s location in The system block diagram is shown in Figure... -
Page 12: Figure 9. Bottom Side Of Da14535 Smartbond Tiny™ Module Db
The marked and numbered sections of the system are: 17. Coin cell battery (BT1) 18. Test points (for more details, see Table 19. Renesas label. Table 3. Test points description Test point Assigned to Comments... -
Page 13: Gpios And Pin Assignment On Da14535 Smartbond Tiny™ Module Db
DA14535 SMARTBOND TINY™ MODULE Development Kit Hardware Test point Assigned to Comments VLED1 Voltage level of RED LED (D1) SWDIO JTAG Interface DIO Signal TP10 VLED2 Voltage Level of Green LED (D2) TP12 RESET Reset TP13 General purpose button (driven from P0_6 signal) TP14 General purpose button (driven from P0_11 signal) TP15... -
Page 14: Figure 10. Gpios Connectivity On Da14535 Smartbond Tiny™ Module Development Kit
DA14535 SMARTBOND TINY™ MODULE Development Kit Hardware DA1453x SMARTBOND DA1453x Pro-MB TINY MODULE DB UART DA14535 SmartBond Tiny Reset/ SWCLK/SWDIO MODULE (U1) MB0_x P0_x Reset circuitry TRIG_x P0_x MB2_x/ MB3_x LEDs, Push Buttons, Debugging header MikroBUS Figure 10. GPIOs connectivity on DA14535 SMARTBOND TINY™ MODULE development kit Figure 11. -
Page 15: Table 4. Gpio Multiplexing On Da14535 Smartbond Tiny™ Module Db
DA14535 SMARTBOND TINY™ MODULE Development Kit Hardware Table 4. GPIO multiplexing on DA14535 SMARTBOND TINY™ MODULE DB DA14535 Function 1 Function 2 Function 3 SMARTBOND connector TINY™ MODULE daughterboard signals P0_0 SW3, RESET Button thru R9 = 4.7K MB2_0 RESET Thru R34=1K P0_2 MB2_2... -
Page 16: Power Section
With the power supply from VLDO of DA1453x Pro-MB, you can measure Current drawn from the DA14535 SMARTBOND TINY™ MODULE by using the current sensing circuit and the power profiler of Renesas SmartSnippets Toolbox. For more information regarding current measurement, see Ref. -
Page 17: Reset Operation
DA14535 SMARTBOND TINY™ MODULE Development Kit Hardware Figure 14. Optional USB power supply section Reset Operation You can reset operation of the DA14535 SMARTBOND TINY™ MODULE using either DA1453x Pro-MB or the DA14535 Module DB. DA1453x PRO-MB DA1453x SMARTBOND TINY MODULE DB Figure 15. -
Page 18: General Purpose Buttons
DA14535 SMARTBOND TINY™ MODULE Development Kit Hardware Figure 16. Reset button on DA14535 SMARTBOND TINY™ MODULE DB General Purpose Buttons Push button SW2 is populated and placed on top side of the board (Figure 18). It is connected to P0_11 (Figure 17) and shares the same configuration with SW2 button of DA1453x Pro-MB (SW2 is connected to P3_1 on the motherboard which is P0_11 on DA14535). -
Page 19: General Purpose Leds
DA14535 SMARTBOND TINY™ MODULE Development Kit Hardware Figure 19. SW2 configuration on DA1453x Pro-MB General Purpose LEDs LED D2 is a general purpose LED, and it is driven by P0_9. LED D1 is driven by P0_8 and it is not populated. You can mount an LED like D2. -
Page 20: Mikrobus™ Module
DA14535 SMARTBOND TINY™ MODULE Development Kit Hardware Figure 22. D5 LED on DA1453x Pro-MB is not driven from DA14535 SMARTBOND TINY™ MODULE MikroBUS™ Module The DA14535 SMARTBOND TINY™ MODULE DB can support MikroBUS™ modules. It requires some level of GPIOs multiplexing to avoid conflict with other functions driven by same GPIOs. A MikroBUS™... -
Page 21: Debugging Interface
DA14535 SMARTBOND TINY™ MODULE Development Kit Hardware Table 5. MikroBUS™ GPIOs multiplexing MikroBUS™ DA14535 SMARTBOND TINY™ Peripherals MODULE GPIOs Other P0_6 P0_11 SDA (default) MISO P0_8 LED D1 SCL (default) P0_9 LED D2 MOSI INT (default) P0_7 Figure 25. Example of mounting MikroBUS™ module Debugging Interface Debugging can be done from SWD and UART interfaces. -
Page 22: Programming And Debugging Interface Setup
DA14535 SMARTBOND TINY™ MODULE Development Kit Hardware Table 7. Pin assignment of debugging connector J2 on DA14535MOD Function Signals Comments DA14535 SMARTBOND TINY™ MODULE DEVKIT (J2) SWCLK P0_2 J2:3 SWDIO P0_10 J2:4 P0_5 J2:2 No enabled (R36 = Not Pop) P0_6 J2:1 No enabled... -
Page 23: 1-Wire Uart, Jtag, Reset
DA14535 SMARTBOND TINY™ MODULE Development Kit Hardware The SPI flash on DA1453x Pro-MB is not used as DA14535 SMARTBOND TINY™ MODULE contains a SPI data Flash. See Table The configurations settings are: ▪ Configuration 1: 1-wire UART, JTAG, and RESET ▪... -
Page 24: Figure 27. Da1453X Pro-Mb Jumper Setup For 1-Wire Uart, Jtag, And Reset Operation
DA14535 SMARTBOND TINY™ MODULE Development Kit Hardware Figure 27. DA1453x Pro-MB jumper setup for 1-wire UART, JTAG, and RESET operation UM-B-173 Revision 1.1 Page 24 July 22, 2024 CFR0012... -
Page 25: 2-Wire Uart, Jtag, Reset
DA14535 SMARTBOND TINY™ MODULE Development Kit Hardware 4.8.2 2-wire UART, JTAG, RESET Table 11. Pin assignment for DA14535 SMARTBOND TINY™ MODULE configuration 2 Configuration P0_0 P0_2 P0_6 P0_5 P0_10 JTAG and 2-wire UART Reset SWLCK SWDIO Figure 28. DA1453x Pro-MB jumper setup for 2-wire UART, JTAG and RESET operation UM-B-173 Revision 1.1 Page 25 July 22, 2024... -
Page 26: 4-Wire Uart, Jtag, Reset
DA14535 SMARTBOND TINY™ MODULE Development Kit Hardware 4.8.3 4-wire UART, JTAG, RESET Table 12. Pin assignment for DA14535 SMARTBOND TINY™ MODULE configuration 3 Configuration P0_0 P0_2 P0_6 P0_5 P0_7 P0_8 P0_10 JTAG and 4-wire UART Reset SWLCK SWDIO Figure 29. DA1453x Pro-MB jumper setup for 4-wire UART, JTAG, and RESET operation UM-B-173 Revision 1.1 Page 26 July 22, 2024... -
Page 27: Known Issues
DA14535 SMARTBOND TINY™ MODULE Development Kit Hardware 5. Known Issues Keil JTAG Default Clock Speed When programing DA14535 SMARTBOND TINY™ MODULE using Keil, the following error may occur when you try to open the debugger session (Figure 30). Figure 30. Keil reported error when opening debugger session You must lower the JTAG clock speed to 2 MHz following the steps shown in Figure Figure 31. -
Page 28: Appendix A Da14535 Smartbond Tiny™ Module Db [610-06-A]
DA14535 SMARTBOND TINY™ MODULE Development Kit Hardware Appendix A DA14535 SMARTBOND TINY™ MODULE DB [610-06-A] A.1 Schematic Figure 32. Schematic of DA14535 SMARTBOND TINY™ MODULE DB [610-06-A] UM-B-173 Revision 1.1 Page 28 July 22, 2024 CFR0012... -
Page 29: A.2 Placed Components
DA14535 SMARTBOND TINY™ MODULE Development Kit Hardware A.2 Placed Components Figure 33. Components on top and bottom sides for DA14535 SMARTBOND TINY™ MODULE DB [610-06-A] UM-B-173 Revision 1.1 Page 29 July 22, 2024 CFR0012... -
Page 30: Revision History
DA14535 SMARTBOND TINY™ MODULE Development Kit Hardware 6. Revision History Revision Date Description July 19, 2024 Changed to company template Mar 22, 2024 Initial version. UM-B-173 Revision 1.1 July 22, 2024 CFR0012... - Page 31 RoHS Compliance Renesas’ suppliers certify that its products are in compliance with the requirements of Directive 2011/65/EU of the European Parliament on the restriction of the use of certain hazardous substances in electrical and electronic equipment. RoHS certificates from our suppliers are available on request.
