  • Page 1 User Manual DA16200 AT GUI Tool UM-WI-004...

  • Page 2: Table Of Contents

    How to Connect ..........................6 USB to Serial Driver ......................6 DA16200 SDK or Firmware Selection ..................6 How to Run GUI with DA16200 EVK .................... 7 Connection and Running....................... 7 COM Port and Baud Rate Configuration................9 RF Certification Mode ......................10 TX Test Mode ........................

  • Page 3: Figures

    UM-WI-004 DA16200 AT GUI Tool Figures Figure 1: DA16200 EVK GUI ......................... 5 Figure 2: Development Kit Connections ....................7 Figure 3: AT GUI ........................... 8 Figure 4: RS232 Setup – Disconnected ....................9 Figure 5: RS232 Setup – Connected ....................9 Figure 6: Debug Console –...

  • Page 4: Terms And Definitions

    Universal Asynchronous Receiver Transmitter User Datagram Protocol Universal Serial Bus References DA16200, Datasheet, Dialog Semiconductor DA16200, SDK Programmer Guide, User Manual, Dialog Semiconductor DA16200, EVK User Guide, Dialog Semiconductor DA16200, AT Command User Guide, Dialog Semiconductor User Manual User Manual Revision 1.7...

  • Page 5: Introduction

    UM-WI-004 DA16200 AT GUI Tool Introduction The DA16200 GUI tool lets users control the DA16200 EVK in a GUI environment. There are three modes of operation: Certification mode, Network mode, and OTP mode (see Figure Figure 1: DA16200 EVK GUI Certification Mode This mode is for Wi-Fi RF test (Tx power, Rx sensitivity, and so on) also known as “TEST Mode”.

  • Page 6: How To Connect

    ● Required the FT232 Driver installation for Windows ○ In most cases, it will be installed automatically The FTDI driver for the FT2232 FTDI chip used on DA16200 EVK is available for download at the following link: http://www.ftdichip.com/Drivers/CDM/CDM21224_Setup.zip ● See the EVK User Guide to find information about the UART1 port.

  • Page 7: How To Run Gui With Da16200 Evk

    Microsoft Visual Studio redistributable package (https://www.microsoft.com/en- us/download/details.aspx?id=48145) or copy the .dll file into the Windows system folder (C:\Windows\System32 or C:\Windows\SysWOW64). The program setup sequence is: Connect the DA16200 Development Kit to the host PC as shown in Figure Figure 2: Development Kit Connections NOTE See the EVK User Guide to know which port to use.

  • Page 8: Figure 3: At Gui

    UM-WI-004 DA16200 AT GUI Tool 4. Start the AT GUI program. Figure 3: AT GUI User Manual User Manual Revision 1.7 Revision 1.7 03-Mar-2022 03-Mar-2022 CFR0012 CFR0012 8 of 29 8 of 29 © 2022 Renesas Electronics © 2022 Renesas Electronics...

  • Page 9: Com Port And Baud Rate Configuration

    UM-WI-004 DA16200 AT GUI Tool COM Port and Baud Rate Configuration 1. When the AT GUI program runs, the connection status is red (not connected). If the program does not detect any COM port, click the Refresh button to refresh the COM Port. See Figure Figure 4: RS232 Setup –...

  • Page 10: Rf Certification Mode

    UM-WI-004 DA16200 AT GUI Tool RF Certification Mode To enable certification mode: 1. Open the Settings tab. See Figure 2. In the RF Mode area, select the Certification Mode check box. Figure 7: Certification Mode Configuration User Manual User Manual Revision 1.7...

  • Page 11: Tx Test Mode

    UM-WI-004 DA16200 AT GUI Tool TX Test Mode 1. Open the Certification Mode tab. See Figure Figure 8: Tx Test Mode Configuration 2. Click the Mode Select button (Figure 8). A confirmation message is shown as in Figure 9. This is a normal state.

  • Page 12: Rx Test Mode

    UM-WI-004 DA16200 AT GUI Tool To do TX packet generation: ● To start and stop TX packet generation, use the Start TX button and the Stop TX button. If you want to make changes for another condition, click Stop TX before a new test is started...

  • Page 13: Figure 13: Rx Configuration

    UM-WI-004 DA16200 AT GUI Tool ● Channel: Support CH1 ~ CH13 ● Test Time: Maximum 3600 s (Duration is 1 second fixed) Figure 13: Rx Configuration ● RX Packet Rate ○ FCS + PHY + Overflow packet / Total packet = Error rate...

  • Page 14: Network Mode

    UM-WI-004 DA16200 AT GUI Tool Network Mode To enable network mode: 1. Open the Settings tab. 2. Select the Network Mode checkbox. See Figure Figure 14: Network Mode Configuration User Manual User Manual Revision 1.7 Revision 1.7 03-Mar-2022 03-Mar-2022 CFR0012...

  • Page 15: Station Mode

    DA16200 AT GUI Tool Station Mode 1. In the Mode Select: field, select Station Mode. ○ The network mode is changed. Next, DA16200 reboots and the station mode setup window opens. See Figure 15 Figure 15: Setup Window – Station Mode 2.

  • Page 16: Figure 17: Station Mode - Choose Ap And Connect

    UM-WI-004 DA16200 AT GUI Tool 3. When scanning is finished, choose one AP in the list. See Figure 17. 4. Click the Connect button. 5. If required by the security mode of the AP, fill in a password or key index.

  • Page 17: Ap Mode

    AP Mode 1. In the Mode Select field, select AP Mode. ○ The network mode changes, DA16200 reboots and the AP Mode setup window opens. See Figure 19 Figure 19: Setup Window – AP Mode 2. Set the fields SSID, Password, Country, Channel, and Security mode. See Figure 3.

  • Page 18: Data Transfer (Tcp/Udp)

    Data Transfer (TCP/UDP) The DA16200 GUI tool provides data transfer functions with TCP/UDP. Before messages are sent with this tool, connect the DA16200 to an access point as shown in Section 7.1. Then click the Data User Manual User Manual Revision 1.7...

  • Page 19: Tcp Server

    X will change to O. See Figure Figure 25: TCP Server Open The user can connect to the DA16200 TCP server with tools for data exchange like the IO Ninja. When a client connects successfully, its information will be shown as in Figure 26.

  • Page 20: Tcp Client

    Figure 27: TCP Client Connection to a Server 7.3.3 UDP Session To open a UDP session, fill in a port number and click the Start button. When the DA16200 TCP client succeeds to connect, the X will change to O. See Figure 28.

  • Page 21: Data Exchange

    UM-WI-004 DA16200 AT GUI Tool 7.3.4 Data Exchange To send a message to a peer, first select a session. Each session is slightly different in method. ● TCP Server: Select the TCP Server checkbox > Select the destination IP in the drop-down list >...

  • Page 22: Data Transfer On Dpm Mode

    3. After all sockets are ready in DPM mode, the DPM_STATUS will change to "DPM sleep". When DA16200 in DPM sleep state receives a TCP or UDP messages from a peer, it is shown in the message window like in...

  • Page 23: Mqtt Client

    DA16200 AT GUI Tool MQTT Client The DA16200 GUI tool provides data transfer functions with MQTT protocol. Before messages are sent with this tool, connect the DA16200 to an access point as shown in Section 7.1. Click the MQTT Client tab. 7.4.1...

  • Page 24: Data Exchange

    2. Click the DPM button to start DPM mode. 3. After the MQTT client session is ready in DPM mode, the DPM_STATUS will change to "DPM sleep". When DA16200 in DPM sleep state receives a PUBLISH from the broker, it is shown in the message window like Figure To send a message in DPM Sleep status: 1.

  • Page 25: Tls Setting

    UM-WI-004 DA16200 AT GUI Tool And to exit DPM mode: 1. Wake up DA16200 with the switch. The DPM_STATUS will change to "DPM Wake-up". 2. Click the Sleep button. The DPM_STATUS will change to "Disabled". TLS Setting The user can store a TLS certificate that is set with this tool for MQTT, HTTPs, CoAPs, and so on.

  • Page 26: Otp Mode Setup

    MAC Address Setup DA16200 has 4 slots to store MAC addresses. The 1st slot is written by Dialog. The user can use 3 slots to write their own MAC address. The MAC address written in the OTP must be an even number.

  • Page 27: Revision History

    UM-WI-004 DA16200 AT GUI Tool Revision History Revision Date Description 28-Mar-2022 Update logo, disclaimer, copyright. 19-Aug-2021 Applied changes to SDK folder hierarchy 06-Jan-2021 Revised as the user interface changes of the tool. 21-Aug-2020 4.3.5 Data Transfer on DPM Mode Modification 4.4.3 MQTT on DPM Mode Modification...
  • Page 28 UM-WI-004 DA16200 AT GUI Tool Status Definitions Status Definition DRAFT The content of this document is under review and subject to formal approval, which may result in modifications or additions. APPROVED The content of this document has been approved for publication.
  • Page 29 Renesas disclaims responsibility for, and you will fully indemnify Renesas and its representatives against, any claims, damages, costs, losses, or liabilities arising out of your use of these resources. Renesas' products are provided only subject to Renesas' Terms and Conditions of Sale or other applicable terms agreed to in writing.
