- Page 1 PLATE LOADED FLY MACHINE V2 CBFLYv2 401494 Operator’s Manual Read the Operator’s Manual entirely. When you see this symbol, the subsequent instructions and warnings are serious follow without exception. Your life and the lives of others depend on it!
- Page 2 PARTS DIAGRAM / EXPLODED VIEW DESCRIPTION DESCRIPTION BASE FRAME BACK CUSHION FRAME (10) HANDLEBAR SEAT CUSHION FRAME (11) CONNECTING FRAME UPRIGHT FRAME (12) BACK CUSHION SUPPORT FRAME (13) SEAT CUSHION SLIDING FRAME (19) FIXING PLATE LEFT ARM FRAME (20) CABLE RIGHT ARM FRAME (23) LOCK PIN...
-
Page 3: Hardware Pack
HARDWARE PACK... - Page 4 HARDWARE PACK...
- Page 5 ASSEMBLY INSTRUCTIONS STEP 1 1. Connect Back Cushion Frame (2) and Upright Frame (4) with Connecting Frame (11), using Flat Washer (38), Nut M10(39) and Carriage Bolt M10*65 (37). 2. Assemble the Knob (23) on the Back Cushion Frame (2). STEP 2 Fix Base Frame (1) on Connecting Frame (11), using Flat Washer (38) and Hex Bolt M10*25 (44).
- Page 6 ASSEMBLY INSTRUCTIONS STEP 3 Plug Sliding Frame (6) into Upright Frame (4). STEP 4 Connect Back Cushion Frame (2), Support Frame (5) and Upright Frame (4), using Fixing Plate (19), Flat Washer (38), Nut M10(39) and Hex Bolt M10*70 (41).
- Page 7 ASSEMBLY INSTRUCTIONS STEP 5 Fix Left & Right Arm Frame (7 & 8), Bearing Washer (18) and Cam (9) on Support Frame (5), using Flat Washer (36), Spring Washer (42) and Hex Bolt M10*20 (43). STEP 6 1. Fix Handlebar (10) on Left & Right Arm Frame (7&8), using Flat Washer (36), Spring Washer (42) and Hex Bolt M10*20(43).
- Page 8 ASSEMBLY INSTRUCTIONS STEP 7 1. Fix Seat Cushion (11) on Seat Cushion Frame (3), using Hex Bolt M10*25 (26) and Flat Washer (24). 2. Fix Back Cushion (6) on Main Frame (1), using Hex Bolt M10*25 (26) and Flat Washer (24). STEP 8 Loose the Screw M8*8(46) on Cam (9), insert one side of Cable (20) into Cam (9), then tighten the Screw M8*8(46).
- Page 9 APPENDIX - FULL ASSEMBLY/EXPLODED VIEW/ FULL PARTS LIST...
- Page 10 APPENDIX - FULL ASSEMBLY/EXPLODED VIEW/ FULL PARTS LIST DESCRIPTION DESCRIPTION BASE FRAME (24) PIPE SLEEVE □50 BACK CUSHION FRAME (25) HOLLOW SLEEVE SEAT CUSHION FRAME (26) STOP COLLAR UPRIGHT FRAME (27) RUBBER BUMPER Φ38*Φ7*15 METAL BUSH SUPPORT FRAME (28) Φ38*Φ32*Φ25.2*18 SLIDING FRAME (29) PULLEY Φ114...
- Page 11 ACKNOWLEDGEMENT OF RISK AND RELEASE OF LIABILITY The use of any equipment, including this one, involves the potential risk of injury. Apart from any warranty claim that might be presented for a claimed defect in material or workmanship of the product, you accept and assume full responsibility for any and all injuries, damages (both economic and non-economic), and losses of any type, which may occur, and you fully and forever release and discharge Titan, its insurers, employees, officers, directors, associates, and agents from any and all claims, demands, damages,...
- Page 12 NEED HELP? CONTACT US FIRST. 1-888-410-1503 info@titan.fitness www.titan.fitness © 2021 Titan Brands...
