3. Specifications

V400m
Terminal
Unit Power
Requirements

Temperature

Humidity

External
Dimensions
Installation Guide
This chapter discusses power requirements, dimensions, and other
specifications of the V400m terminal and bases:
Refer to the following specifications for the V400m terminal:
•
Operating power: 5V DC, 2.2A
•
Operating temperature: - 0° to 40°C (32° to 104°F)
•
Storage temperature: - 20° to 60°C (-4° to 140°F)
•
Relative humidity: 5% to 93% (RH non-condensing)
V400m Plus 4G
•
Length: 161 mm (6.34 in)
•
Width: 72.75 mm (2.86 in)
•
Depth: 56.85 mm (2.23 in)
V400m Plus 4G WW
•
Length: 164 mm (6.46 in)
•
Width: 72.75 mm (2.86 in)
•
Depth: 56.85 mm (2.23 in)
V400m-2
•
Length: 164 mm (6.46 in)
•
Width: 72.75 mm (2.86 in)
•
Depth: 56.85 mm (2.23 in)
V400m
