Getting started with your Verifone v240m pay terminal NEXT...
Page 2
Getting started Thank you for ordering the Verifone v240m payment terminal. Your terminal is locked for security reasons. This guide explains how to unlock and activate your terminal, and how to perform transactions. You will require your Merchant Number, which can be found within your welcome pack or e-mail.
Contents • Power-up and Activation • Adding Wi-Fi • Performing a Sale • Performing a Refund • Performing a Reconciliation BACK TO START PREVIOUS NEXT...
Power-up and Activation Power-up and Activation BACK TO CONTENTS PREVIOUS NEXT...
Page 5
Power-up and Activation Plug the power supply into the power slot of the V240m base unit. BACK TO CONTENTS PREVIOUS NEXT...
Page 6
Power-up and Activation Place the V240m terminal onto the base unit, and switch the power on. BACK TO CONTENTS PREVIOUS NEXT...
Page 7
Power-up and Activation The V240m will initialise. BACK TO CONTENTS PREVIOUS NEXT...
Page 8
Power-up and Activation When you see the 'Terminal Locked' screen, key in your Merchant Number as the password and press the green [ENTER] key. green [ENTER] Press the key twice more until the Sale Screen is displayed. BACK TO CONTENTS PREVIOUS NEXT...
Page 9
Power-up and Activation You are now ready to take payments. Your V240m terminal is pre- configured to use either the 3G mobile network or Bluetooth for communications. This will allow you to authorise sales immediately. You can also enable Wi-Fi as the primary communications method.
Adding Wi-Fi Adding Wi-Fi BACK TO CONTENTS PREVIOUS NEXT...
Page 11
Adding Wi-Fi Press the main logo at the top of the screen. On Main Menu (1/2), press the down arrow. BACK TO CONTENTS PREVIOUS NEXT...
Page 12
Adding Wi-Fi Press 1 on the keypad or select Configuration on screen. BACK TO CONTENTS PREVIOUS NEXT...
Page 13
Adding Wi-Fi Enter the supervisor password (default 1234). Press 1 on the keypad. BACK TO CONTENTS PREVIOUS NEXT...
Page 14
Adding Wi-Fi You should now see the Communication Panel. Drag the screen downwards (as per a smartphone) and touch Configuration. BACK TO CONTENTS PREVIOUS NEXT...
Page 15
Adding Wi-Fi Select Network Interface. BACK TO CONTENTS PREVIOUS NEXT...
Page 16
Adding Wi-Fi Select WiFi. Select WiFi Scan. BACK TO CONTENTS PREVIOUS NEXT...
Page 17
Adding Wi-Fi Select your desired network from the list of detected networks. BACK TO CONTENTS PREVIOUS NEXT...
Page 18
Adding Wi-Fi Select Add. Select Pre-Shared-Key (PSK). BACK TO CONTENTS PREVIOUS NEXT...
Page 19
Adding Wi-Fi Enter the Wi-Fi password / key. Select OK. BACK TO CONTENTS PREVIOUS NEXT...
Page 20
Adding Wi-Fi Select Save. Select OK. BACK TO CONTENTS PREVIOUS NEXT...
Page 21
Adding Wi-Fi Select Yes. Select OK. BACK TO CONTENTS PREVIOUS NEXT...
Page 22
Adding Wi-Fi Press the Cancel button 6 times until you reach the Sale screen. Wi-Fi should now be set up. For details on other transactions, reports and general functionality of the device, please refer to the full user manual. BACK TO CONTENTS PREVIOUS NEXT...
Performing a Sale Performing a Sale BACK TO CONTENTS PREVIOUS NEXT...
Page 24
Performing a Sale While the terminal is on the main screen, key in the amount for the sale and press [ENTER] key. If tip is configured, select the tip value. Tip screens will only be shown if tip is enabled. BACK TO CONTENTS PREVIOUS NEXT...
Page 25
Performing a Sale Total amount = Sale amount + Tip amount BACK TO CONTENTS PREVIOUS NEXT...
Page 26
Performing a Sale Present, insert or swipe the payment card, or, manually enter the card number for MOTO. If cashback is enabled, you will be prompted to ask if cashback is required. BACK TO CONTENTS PREVIOUS NEXT...
Page 27
Performing a Sale If cashback is required, enter the cash amount and press [ENTER] key. Total amount = Sale amount + Cashback amount BACK TO CONTENTS PREVIOUS NEXT...
Page 28
Performing a Sale If a card was inserted, enter the PIN. At this stage, the terminal will contact the acquirer and will provide a result, e.g. Approved, Declined, Referred. BACK TO CONTENTS PREVIOUS NEXT...
Page 29
Performing a Sale You will need to retain the first receipt for your records. BACK TO CONTENTS PREVIOUS NEXT...
Page 30
Performing a Sale If selected, the second receipt is to be given to the customer. If the customer’s payment card was inserted, it can now be removed. BACK TO CONTENTS PREVIOUS NEXT...
Page 31
Performing a Sale The terminal will then return to the main screen. BACK TO CONTENTS PREVIOUS NEXT...
Performing a Refund Performing a Refund BACK TO CONTENTS PREVIOUS NEXT...
Page 33
Performing a Refund Touch the main logo at the top of the screen. From the main menu, select Onetime Transactions and then select Refund. BACK TO CONTENTS PREVIOUS NEXT...
Page 34
Performing a Refund Enter the Supervisor password. Enter the refund amount and press [ENTER] key. BACK TO CONTENTS PREVIOUS NEXT...
Page 35
Performing a Refund Present, insert or swipe the payment card, or, manually enter the card number for MOTO. BACK TO CONTENTS PREVIOUS NEXT...
Page 36
Performing a Refund You will need to retain the first receipt for your records. If selected, the second receipt is to be given to the customer. BACK TO CONTENTS PREVIOUS NEXT...
Page 37
Performing a Refund If the customer’s payment card was inserted, it can now be removed. The terminal will return to the main screen. BACK TO CONTENTS PREVIOUS NEXT...
Performing a Reconciliation Performing a Reconciliation BACK TO CONTENTS PREVIOUS NEXT...
Page 39
Performing a Reconciliation Touch the main logo at the top of the screen. Select Reports from the menu and enter the Supervisor password. BACK TO CONTENTS PREVIOUS NEXT...
Page 40
Performing a Reconciliation Select the acquirer/s to reconcile. BACK TO CONTENTS PREVIOUS NEXT...
Page 41
Performing a Reconciliation The terminal will connect to each of the selected acquirers in turn and transmit your totals. BACK TO CONTENTS PREVIOUS NEXT...
Page 42
Performing a Reconciliation A report will be printed for your records. BACK TO CONTENTS PREVIOUS...
