DEMO MANUAL DC2491A

PARTS LIST

ITEM QTY REFERENCE
Required Circuit Components
1 1 CIN
2 2 C1, C4
3 1 C2
4 1 R1
5 1 R3
6 1 R5
7 1 R6
8 1 R7
9 1 U1
Optional Electronic Components
1 0 C3, C5 (OPT)
2 0 R2, R4 (OPT)
3 1 R8
Hardware
1 6 E1 – E6
2 1 JP1
3 1 XJP1
4 2 J1, J2
5 4 MH1 – MH4
6
PART DESCRIPTION
CAP ., ALUM, 22µF, 35V, 5mm × 5.4mm
CAP ., X7R, 4.7μF, 25V, 10% 1206
CAP ., X5R, 10μF, 25V, 10% 1206
RES., CHIP , 200k, 1/16W, 5% 0603
RES., CHIP , 33.2k, 1/8W, 1% 0603
RES., CHIP , 453k, 1/8W, 1% 0603
RES., CHIP , 49.9k, 1/8W, 1% 0603
RES., CHIP , 249Ω, 1/16W, 1% 0603
IC, LT3045EDD DFN 3mm × 3mm
CAP ., 1206
RES., 0603
RES., CHIP , 0Ω, 1/16W, 5% 0603
TESTPOINT, TURRET, 0.094" PBF
HEADER 3-PIN 0.079" DOUBLE ROW
SHUNT, 0.079" CENTER
CONN, BNC, 5 PINS
STAND-OFF , NYLON 6.4mm
MANUFACTURER/PART NUMBER
SUN ELECTRONIC INDUSTRIES CORP ., 35CE22BSS
MURATA, GRM31CR71E475KA88L
MURATA, GJ831CR61E106KE83L
VISHAY, CRCW0603200KJNED
VISHAY, CRCW060333K2FKEA
VISHAY, CRCW0603453KFKEA
VISHAY, CRCW060349K9FKEA
VISHAY, CRCW0603249RFKEA
LINEAR TECH., LT3045EDD#PBF
VISHAY, CRCW06030000Z0EA
MILL-MAX, 2501-2-00-80-00-00-07-0
WURTH ELEKTRONIK, 62000621121
WURTH ELEKTRONIK, 60800213421
CONNEX, 112404
WURTH ELEKTRONIK, 702931000
