Parts List - Linear Technology DC1789A Demo Manual

DEMO MANUAL DC1789A

parts list

ITEM QTY
Required Circuit Components
1 1
Hardware/Components (For Demo Board Only)
2 1
3 1
4 1
5 1
6 3
7 3
8 4
6
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
REFERENCE PART DESCRIPTION
U1 I.C., LTM2884CY
C1 CAP ., TANT 22F 25V 20% 'C'
C2 CAP ., TANT 100F 10V 20% 'C'
J1 USB RECEPTACLE TYPE B
J2 USB RECEPTACLE TYPE A
JP1-4 0.1" SINGLE ROW HEADER, 3-PIN
JP1-4 SHUNT
TP1-4 TESTPOINT, TURRET, 0.095
MANUFACTURER/PART NUMBER
LINEAR LTM2884CY#PBF
AVX TAJC226M025R
AVX TPSC107M010R0150
MILL-MAX 897-43-004-90-00000
MILL-MAX 896-43-004-90-00000
SAMTEC TSW-103-26-L-S
SAMTEC SNT-100-BK-G
MILL-MAX 2501-2-00-80-00-00-07-0
dc1789afa
