- Page 1 Rev. 905-0175-00 3G-SDI × 4ch 4K UHDTV CMOS Color Camera Module DCC-4K2 Product Specification & Operational Manual CIS Corporation ©2019 CIS Corporation. All rights reserved.
-
Page 2: Table Of Contents
Factory Settings ............................23 Dimensions ................................24 6.1. Camera Dimensions ........................... 24 Case for Indemnity (Limited Warranty) ........................25 7.1. Product Warranty ............................25 7.2. CMOS Defective Pixels ..........................25 Product Support ..............................25 ©2019 CIS Corporation. All rights reserved. -
Page 3: Handling Precautions
□ The camera module must not be used under conditions or environments other than those specified in this manual. 1.3. Disclaimers (Exception Clause) CIS should not be liable for any damages or losses if; damages or losses are caused by earthquake, lightning strike, fire, flood, or other acts of God. ・... -
Page 4: Product Outline
DCC-4K2 Rev. 905-0175-00 Product Outline DCC-4K2 is a 4K UHDTV color camera module without casing/chassis. Using a 1.0” global shutter CMOS image sensor, the maximum frame rate achieves 60fps. 3G-SDI x 4ch interface and features CIS proprietary ISP, “Clairvu ” image processing engine for superb imaging quality and high speed processing. -
Page 5: Specifications
Complies with BT.709 curve : Contrast -2, -1, 0, +1, +2 Complies with BT.2100 (HLG) Dynamic range Low (for better SNR), Normal, High Knee point OFF, 100%, 95%, 90%, 85%, 80%, 75% Color gamut BT.709, BT.2020 Master pedestal -100 ~ 0 ~ +100 ©2019 CIS Corporation. All rights reserved. - Page 6 Storage Temperature -30 ~ +60°C Humidity: 20 ~ 80%RH with no condensation. ※1). Conditions: Screw the lens mount block and main block to a flat aluminum plate in size of W100 x D150 x H3mm. ©2019 CIS Corporation. All rights reserved.
-
Page 7: External Connector
Reserved (Do not connect) Reserved (Do not connect) TEST terminal (Do not connect) RS-232C RXD In (Camera) RS-232C TXD Out (Camera) Reserved (Do not connect) Reserved (Do not connect) Reserved (Do not connect) Reserved (Do not connect) ©2019 CIS Corporation. All rights reserved. -
Page 8: Small Size Bnc Jack
3G-SDI output CH3 (Lower right for SQD) Shell Chassis GND 3.2.4 mini USB Connector Model Name: UX60R-MB-5ST (HIROSE) Pin No. Description USB VBAS USB D- USB D+ [Note] Do not connect USB signals when power is OFF. ©2019 CIS Corporation. All rights reserved. -
Page 9: Camera Functions
ON, and when signals are input to the LTC IN terminal, time code switches to external time code. Under this condition, if no signal is input to the LTC IN terminal, internal time code starts. Signal format: SMPTE Time code Signal level: 0.5~2[Vp-p] ©2019 CIS Corporation. All rights reserved. -
Page 10: Defective Pixel Correction
For example, if the defective pixel is at (943, 0), the data is registered only to region 0. However, if the defective pixel is at (944, 0), the data is registered to both region 0 and 1 ©2019 CIS Corporation. All rights reserved. -
Page 11: Notes For Defective Pixel Correction
“Set”), and the other is GU command (“G” for “Get”) to obtain information from the camera. Command Parameter 1 Parameter 2 Function Address Normally None To obtain camera setting information. (There are exceptions in some cases) Address Data (There may be more than one) To change camera settings. ©2019 CIS Corporation. All rights reserved. - Page 12 【Example of SU command】 To set 30 to address 10 [Send] SU [sp] 10[sp] 30[¥r] [Returned value] SU [sp] 10[sp] 30[¥r] [¥n] [Echo back] [Returned value] [¥r] [¥n] [Linefeed] [Returned value] > [sp] [Prompt (> and space)] ©2019 CIS Corporation. All rights reserved.
-
Page 13: Command List
18: UHDTV 2-Sample Interleave 30p 444 (Level A) 19: UHDTV 2-Sample Interleave 29.97p 444 (Level A) 20: UHDTV 2-Sample Interleave 25p 444 (Level A) 21: UHDTV 2-Sample Interleave 24p 444 (Level A) 22: UHDTV 2-Sample Interleave 23.98p 444 (Level A) ©2019 CIS Corporation. All rights reserved. - Page 14 ※Please refer to Section 5.4 Quick Reference Table Setting range: (77) 1/13600 ~ 1/23.98s 1/13600s for Shutter Settings. (0x4D~0xAAD6） 0： Average 1： Center-Weighted Metering mode This is to set metering mode. 2： Spot 3： Backlight Compensation ©2019 CIS Corporation. All rights reserved.
- Page 15 (*1) Due to physical limitation of the sensor and circuit, there are some cases that user cannot control values and limits of gain and shutter as designated by commands. User can check the actual values with Current Gain and Current Shutter commands. ©2019 CIS Corporation. All rights reserved.
- Page 16 This is to acquire the current Red Gain. Current Red gain None None (Dedicated to GU) This is to acquire the current Blue Gain. Current Blue gain None None (Dedicated to GU) ©2019 CIS Corporation. All rights reserved.
- Page 17 Equivalent to 1200% for HLG [HLG] 50% output level is regarded as 100% input level. Color saturation 0~200(%) This is to set color saturation. 0 : Off Noise reduction This is to set noise reduction. 1 : On ©2019 CIS Corporation. All rights reserved.
- Page 18 DC Iris Response 0 (Slow) ~ 15 (Fast) Speed When hunting occurs, please set smaller value and adjust the response speed according to the characteristics of DC Iris lens used. ©2019 CIS Corporation. All rights reserved.
- Page 19 OSD menu. 3: Magenta Highlight color 4: Green If user specifies the same color as the 5: Cyan text color, error will occur because the 6: Yellow selected letters cannot be recognized. 7: White ©2019 CIS Corporation. All rights reserved.
- Page 20 SU100), this command saves the stored data, the address to store, and defective pixel correction data. (SU Only) Microcomputer version Version information None This is to acquire version information. (GU Only) 2: FPGA version ©2019 CIS Corporation. All rights reserved.
- Page 21 of pixels classified under [P] attribute. User can change only user register data, and cannot remove the factory setting data. User cannot register the pixels already been registered as factory data. ©2019 CIS Corporation. All rights reserved.
-
Page 22: Quick Reference Table For Gain Settings
6658043 006597FB 114.035 41.141 7473400 007208F8 128.000 42.144 8388608 00800000 143.675 43.148 9415894 008FACD6 161.270 44.151 10568984 00A14518 181.019 45.154 11863283 00B504F3 203.187 46.158 13316085 00CB2FF5 228.070 47.161 14946800 00E411F0 251.189 48.000 16461899 00FB304B ©2019 CIS Corporation. All rights reserved. -
Page 23: Quick Reference Table For Shutter Settings
000016C1 1/250 4194 00001062 1/350 2996 00000BB4 1/500 2097 00000831 1/725 1446 000005A6 1/1000 1049 00000419 1/1500 000002BB 1/2000 0000020C 1/3000 0000015E 1/4000 00000106 1/6000 000000AF 1/8000 00000083 1/9600 0000006D 1/11200 0000005E 1/13600 0000004D ©2019 CIS Corporation. All rights reserved. -
Page 24: Factory Settings
Color Suppression Color Space BT.709 DC Iris Mode Open DC Iris Response Speed Text Color White Highlight Color Cyan Camera Setting Store/Load LTC Mode GenLock V Offset GenLock H Offset H Flip V Flip ©2019 CIS Corporation. All rights reserved. -
Page 25: Dimensions
Make sure to take appropriate heat dissipation measures to use this camera module. Recommendation: Screw lens mount block and main block to a flat aluminum plate in size of W100 x D150 x H3mm. ©2019 CIS Corporation. All rights reserved. -
Page 26: Case For Indemnity (Limited Warranty)
CIS applies defective pixel correction prior to the shipment of the product. However, the number of defective pixels are subject to increase due primarily to the effect of cosmic rays. Due to this nature, CIS should not hold responsible for the natural increase of defective pixels.
