VCC-FC41SX29CL
Rev.900-696-32-00
English
6M CMOS Color (RAW)
Camera Link Camera
VCC-FC41SX29CL
Product Specification
& Operational Manual
CIS Corporation
©2011 CIS Corporation. All rights reserved.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VISION:elite VCC-FC41SX29CL and is the answer not in the manual?

Questions and answers

Related Manuals for CIS VISION:elite VCC-FC41SX29CL

Summary of Contents for CIS VISION:elite VCC-FC41SX29CL

  • Page 1 VCC-FC41SX29CL Rev.900-696-32-00 English 6M CMOS Color (RAW) Camera Link Camera VCC-FC41SX29CL Product Specification & Operational Manual CIS Corporation ©2011 CIS Corporation. All rights reserved.

  • Page 2: Table Of Contents

    10. Initial Settings ..............................27 11. CCD Optical Axis Accuracy ............................ 28 12. Dimensions ................................29 13. Cases for Indemnity (Limited Warranty) ......................... 30 14. CMOS Pixel Defect ..............................30 15. Product Support ..............................30 ©2011 CIS Corporation. All rights reserved.

  • Page 3: Scope Of Application

    Do not apply excessive force or static electricity that could damage the camera. Do not shoot direct images that are extremely bright (e.g., light source, sun, etc.), and when camera is not in use, put the lens cap on. ©2011 CIS Corporation. All rights reserved.
  • Page 4 The rising time of camera power supply voltage shall be less than +10V, Max 60ms. Please avoid noises like chattering when rising. Voltage Rising Time [ ms ] In case of abnormal operation, contact the distributor from whom you purchased the product. ©2011 CIS Corporation. All rights reserved.

  • Page 5: Product Outline

    15fps ～ 134fps at partial scan mode (Valid only at trigger mode.) Bundled Items Camera □ CIS Control Panel Software (For evaluation and demonstration purpose). ※ □ Please ask for the details or download it from our web. ※ ©2011 CIS Corporation. All rights reserved.

  • Page 6: Specification

    1/60 ～ 1/120000s (1H step) range 15fps Mode: 1/15 ～ 1/34000s (1H step) (19) Trigger Mode ・Fixed Shutter Trigger Mode/Fixed Shutter Trigger Mode (Pseudo-reset shutter) ・Pulse Width Shutter Trigger Mode/Pulse Width Shutter Trigger Mode (Pseudo-reset shutter) ©2011 CIS Corporation. All rights reserved.
  • Page 7 With no condensation. guaranteed Temperature ※Performance guaranteed: Specified values in this Specifications are guaranteed. ※Operation guaranteed: Camera functions are operated normally. (23) Storage environment -25 ～ +60℃ RH 20 ～ 80%RH With no condensation. ©2011 CIS Corporation. All rights reserved.

  • Page 8: Camera Output Signal Specification

    5 seconds shall be waited after turning on power to get proper camera operation. ※ +5.0V( VCC ) LVAL/FVAL/DVAL/ 100Ω Trigger Output(6pin), Exposure Output(9pin) HD74LV1GT32 ACME (RENESAS) Voh:3.8V(Min) Vol:0.55V(Max) 100Ω Trigger Input(11pin) HD74LV1GT14 ACME (RENESAS) Vt-:0.5V(Min) Vt+:1.9V(Max) 12pins circular connector at rear, IO Interface ©2011 CIS Corporation. All rights reserved.

  • Page 9: Spectral Response (Representative Value)

    VCC-FC41SX29CL Rev.900-696-32-00 4.3 . Spectral Response (Representative Value) ※ Lens characteristics, IR cut filter, and luminous source characteristics are not considered. ©2011 CIS Corporation. All rights reserved.

  • Page 10: Video Output Format

    (1) 60fps mode : Base Configuration × 2 6Taps Separated Output Format (Initial Setting) Camera Link output (2) 60fps mode : Base Configuration × 2 6Taps Interleaved Output Format Camera Link output (3) 15fps mode : Base Configuration × 1 2Taps Interleaved Output Format Camera Link output ©2011 CIS Corporation. All rights reserved.

  • Page 11: Function Settings

    Address 009 MSB and Address 010 LSB make 16bit in total. 60fps mode: Shutter Speed = (2309 - (009&010) + 1)×7.222μs 15fps mode: Shutter Speed = (2309 - (009&010) + 1)×28.889μs Max. Data = 2309 Trigger Polarity Positive Input Negative Input ©2011 CIS Corporation. All rights reserved.
  • Page 12 ※Set the data of Address 003 to 004. Manual White Balance G 186&187 256～1023: 256:×1(0dB)～1023:×4(+12dB) ※Set the data of Address 003 to 004. Data Save Input 083 or 053 to save the data to EEP-ROM. ©2011 CIS Corporation. All rights reserved.

  • Page 13: External Connector Pin Assignment

    Rev.900-696-32-00 6. External Connector Pin Assignment 6.1. 12 pins Circular Connector HR10-10R-12PA (HIROSE) Pin No. DC +12V IN LVAL/FVAL/DVAL/Trigger Output ※1 Exposure Signal Output Trigger Input ※ LVAL/FVAL/DVAL/Trigger Output are selectable with Address 034. ©2011 CIS Corporation. All rights reserved.

  • Page 14: Camera Link Connector 12226-1100-00Pl (Sumitomo 3M)

    Pin No. Pin No. Yclk- Yclk+ Xclk- Xclk+ 100Ω Terminated SerTC+ SerTC- SerTFG- SerTFG+ CC1- (Trigger IN -) CC1+ (Trigger IN +) NC (CC2+) NC (CC2-) NC (CC3-) NC (CC3+) NC (CC4+) NC (CC4-) ©2011 CIS Corporation. All rights reserved.

  • Page 15: Timing Chart

    ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ Camera Link Output LVAL DVAL H Blanking Back Porch Front Porch Effective Data : 480 CLK : 22 CLK : 10 CLK : 8 CLK 1H = 520 Camera Link CLK ©2011 CIS Corporation. All rights reserved.

  • Page 16: Horizontal Synchronous Timing (15Fps Mode)

    Vertical Synchronous Timing, Normal Shutter Mode (Trigger Shutter Mode OFF) 有効ライン CMOS 有効ライン 出力 FVAL LVAL DVAL Back Front Porch Porch 有効ライン :2184H V Blanking : 98 H : 4 H : 24H ： 2310 H フレーム総ライン ©2011 CIS Corporation. All rights reserved.

  • Page 17: 60Fps Trigger Shutter Mode Timing

    : Shutter Time + Video Output Time 60fps Pulse Width Trigger Shutter Mode (Progressive: 16.683ms) Trigger signals input prior to the completion of video output signals for the prior trigger shall be □ ignored. ©2011 CIS Corporation. All rights reserved.

  • Page 18: 60Fps Fixed Trigger Shutter Mode

    Exposure Signal Period Exposure Pulse Width Signal Output Video Output Time Time (16.683ms Fixed) (Shutter Time) 2310H Trgger Input Invalid Area (Pulse Width Time + Video Output Time) Strobo LVAL output cannot be guaranteed. ©2011 CIS Corporation. All rights reserved.

  • Page 19: 60Fps Trigger Shutter Mode (Pseudo-Reset Shutter)

    (16.033ms) + Shutter Time 60fps Pulse Width Trigger Shutter Mode (Pseudo-Reset Shutter) + Video Output Time (Progressive: 16.683ms) Trigger signals input prior to the completion of video output signals for the prior trigger shall be □ ignored. ©2011 CIS Corporation. All rights reserved.

  • Page 20: 60Fps Fixed Trigger Shutter Mode (Pseudo-Reset Shutter)

    Video Output Time (16.683ms Fixed) (16.683ms Fixed) Pulse Time (Shutter Time) Trigger Input Invalid Area (Dummy Read Out Time + Pulse Width Time + Video Output Time) Strobo ： LVAL output cannot be guaranteed. ©2011 CIS Corporation. All rights reserved.

  • Page 21: 15Fps Trigger Shutter Mode Timing

    : Shutter Time + Video Output Time 15fps Pulse Width Trigger Shutter Mode (Progressive: 66.733ms) Trigger signals input prior to the completion of video output signals for the prior trigger shall be □ ignored. ©2011 CIS Corporation. All rights reserved.

  • Page 22: 15Fps Fixed Trigger Shutter Mode

    Exposure Signal ? ? Signal Output Video Output Time Pulse Width Time (66.733ms Fixed) (Shutter Time) 2310H Trigger Input Invalid Area (Pulse Time + Video Output Time) Strobo : LVAL output cannot be guaranteed. ©2011 CIS Corporation. All rights reserved.

  • Page 23: 15Fps Trigger Shutter Mode Timing (Batch-Reset Shutter/Pseudo-Reset Shutter)

    : Dummy Read Out Time (66.733ms) + Shutter Time + Video Output Time (Progressive: 66.733ms) Trigger signals input prior to the completion of video output signals for the prior trigger shall be □ ignored. ©2011 CIS Corporation. All rights reserved.

  • Page 24: 15Fps Fixed Trigger Shutter Mode (Batch-Reset Shutter)

    Dummy Read Out Time Signal 期間 (66.733ms Fixed) (66.733ms Fixed) Pulse Width Time (Shutter Time) 2310H Trigger Input Invalid Area (Dummy Read Out Time＋ Pulse Width Time+ Video Output Time) Strobo ： LVAL output cannot be guaranteed. ©2011 CIS Corporation. All rights reserved.

  • Page 25: Partial Scan Mode Details

    ・ ・ ・ ・ ・ 15 (vertical: UXGA equiv.) 1248 H 1398 H 25 fps 99 fps ・ ・ ・ ・ ・ 27 (Max: total lines) 2184 H 2310 H 15 fps 60 fps ©2011 CIS Corporation. All rights reserved.

  • Page 26: Remote Interface Function

    To save the data into EEPROM, please refer to Section 5.Function Settings. C is the code to send the data back from the camera. Note: Do not set code C when sending the data from PC side. ©2011 CIS Corporation. All rights reserved.

  • Page 27: Initial Settings

    Partial Scan Effective Lines 019&020 27: 2184 lines Partial Scan Total Lines 029&030 2309: (Read Only) 12pins Connector Output LVAL Output Exposure Signal Polarity Positive Output 60fps Mode Output Format 036 6 Taps Separated Output Format ©2011 CIS Corporation. All rights reserved.

  • Page 28: Ccd Optical Axis Accuracy

    Product Name Label Position ( ? ) Inclination of effective pixels “Theta” to datum plane is ?? ±1° 910-012-00-00 (Unit: mm) *) Dimensions from datum plane to the center of the lens mount. ©2011 CIS Corporation. All rights reserved.

  • Page 29: Dimensions

    Depth 3 999-521-00-00 (Unit: mm) *) C mount screws comply with ANSI/ASME B1.1, 1-32UN(2B). *) Screw length from C mount lens surface shall be under 6mm. And protruding portion shlal be less than 10mm. ©2011 CIS Corporation. All rights reserved.

  • Page 30: Cases For Indemnity (Limited Warranty)

    Expenses we bear on this product shall be limited to the individual price of the product. 14. CMOS Pixel Defect CIS compensates the noticeable CMOS pixel defects found at the shipping inspection prior to our shipment. On very rare occasions, however, CMOS pixel defects might be noted with time of usage of the products.
