VCC-120CXP1M/VCC-120CXP1R
Preliminary Rev.905-0120-Z1
CoaXPress I/F
120M pixels CMOS Cameras
VCC-120CXP1M
VCC-120CXP1R
Product Specifications
& Operational Manual
(Preliminary Version 1)
CIS Corporation

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VCC-120CXP1M and is the answer not in the manual?

Questions and answers

Related Manuals for CIS VCC-120CXP1M

Summary of Contents for CIS VCC-120CXP1M

  • Page 1 VCC-120CXP1M/VCC-120CXP1R Preliminary Rev.905-0120-Z1 CoaXPress I/F 120M pixels CMOS Cameras VCC-120CXP1M VCC-120CXP1R Product Specifications & Operational Manual (Preliminary Version 1) CIS Corporation...

  • Page 2: Table Of Contents

    4.18. How to Save and Intialize the Settings ......................18 Factory Settings ..............................19 Dimensions ................................20 6.1. Camera Dimensions ............................20 6.2. Optical Axis Accuracy ............................21 Case for Indemity (Limited Warranty) ........................22 7.1. Product Warranty ............................22 7.2. CMOS Pixel Defect ............................22 7.3. Product Support .............................22 ©2017 CIS Corporation. All rights reserved.

  • Page 3: Handling Precautions

    1.3. Disclaimers (Exception Clause) CIS shall be exempted from taking responsibility and held harmless for damages or losses incurred by the following cases. □ In case damages or losses are caused by earthquake, lightning strike, fire, flood disaster, or other acts of God.

  • Page 4: Prouct Outline

    VCC-120CXP1M/VCC-120CXP1R Preliminary Rev.905-0120-Z1 Prouct Outline VCC-120CXP1M and VCC-120CXP1R are CoaXPress interfaced cameras utilizing APS-H type, 120M pixels CMOS image sensors. VCC-120CXP1M: B/W camera VCC-120CXP1R: Color camera 2.1. Features □ Rolling shutter type CMOS sensor □ CoaXPress CXP-3 and CXP-6 □ 4 Lanes or 2 Lanes □...

  • Page 5: Specifications

    3 Preset patterns (8192x4096, 3840x2160, 1920x1080) Power requirements 12pins circular connector (12～24V) or PoCXP Power consumption 7.0W (CXP6_X4), [At free run] Mechanical Specifications Dimensions H:65mm W:65mm D:68mm (Without protruding portion) Weight Approx. 300g Lens Mount M48 mount ©2017 CIS Corporation. All rights reserved.
  • Page 6 +5.0V (CAMERA_INTERNAL) SIGNAL_OUT HD74LV1GT32ACME 3.1.3 FVALL_OUT/LVAL_OUT (12pins circular connector, No. 6, 7, and 10 pin） □ 5.0V CMOS Logic level output □ Output voltage Low: 0.55Vdc (Max), High: 3.8Vdc (Min) +5.0V (CAMERA_INTERNAL) SIGNAL_OUT HD74LV1GT32ACME ©2017 CIS Corporation. All rights reserved.

  • Page 7: External Connector Pin Assignment

    Confirmed connection of the device and the host. Green Fast Blinking [12.5Hz] Transmitting video data. Orange Slow Blinking [1Hz] Waiting for the trigger input Red Slow Blinking [0.5Hz] Image transmission error occurred or inappropriate trigger input. ©2017 CIS Corporation. All rights reserved.

  • Page 8: Spectral Response

    3.3. Spectral Response 3.3.1 Spectral Response for B/W Sensor ※ The lens characteristic and the illuminant characteristics are excluded. 3.3.1 Spectral Response for Color Sensor ※ The lens characteristic and the illuminant characteristics are excluded. ©2017 CIS Corporation. All rights reserved.

  • Page 9: Camera Operational Function

    ： Indicate the communication status of CoaXPress ・ ErrorStatus ： OFF at normal operation. Lights only when video transmitting error occurs or when an inappropriate trigger is input. ・ Inactive ： ALL LED OFF ©2017 CIS Corporation. All rights reserved.

  • Page 10: Partial Scan (Roi)

    9.39 ROIQuickChange8192x4096 mono8/BayerBG8 20.94 20.94 20.94 (8192x4096,2536,2542) mono10/BayerBG10 20.94 ROIQuickChange3840x2160 mono8/BayerBG8 39.41 39.41 39.41 (3840x2160,4712,3510) mono10/BayerBG10 39.41 ROIQuickChange1920x1080 mono8/BayerBG8 77.54 77.54 77.54 FullHD (1920x1080,5672,4050) mono10/BayerBG10 77.54 ※Bayer BG is only for color model. ©2017 CIS Corporation. All rights reserved.

  • Page 11: Pixelformat

    □ Test pattern can be output from the camera. It is useful to check if your system is operating properly. B/W model： Gray scale Color model： Color bar ImageFormatControl TestImageMode ON/OFF 〔Note〕 Test pattern indication function cannot be set when cursor indication is ON. ©2017 CIS Corporation. All rights reserved.

  • Page 12: Trigger Mode

    ： External trigger input from the 12pins circular connector. TriggerSoftware： Software trigger A trigger is generated in the camera and capture images for one frame when this command is executed. This command is valid when TriggerSelector is at FrameStart. ©2017 CIS Corporation. All rights reserved.
  • Page 13 Read out Read out Read out Vscan Vscan Vscan FVAL_OUT LVAL_OUT … … STRB_OUT Long Time Exposure Mode ※When exposure time is 4.5 frames, it shall be rounded so that frame cycle becomes 5 frames. ©2017 CIS Corporation. All rights reserved.
  • Page 14 Standard Exposure Mode ※Compared to the standard exposure at internal sync mode, its frame cycle becomes two frames more and over. ©2017 CIS Corporation. All rights reserved.
  • Page 15 ※When exposure time is 4.5 frames, it shall be rounded up so that its frame cycle becomes six frames more and over, compared to the frame cycle of standard exposure at internal sync mode. ©2017 CIS Corporation. All rights reserved.

  • Page 16: Strobe Pulse Control

    Note) If a line number, more than trigger cycle was set, abnormal operation may occur. trig … Accumlation Period previous Reset frame Vscan Read out Vscan Narrow strobe Wide strobe strobe_width strobe_dly Manual strobe ©2017 CIS Corporation. All rights reserved.

  • Page 17: Exposure Time

    When a preset gain is set, it shall be reflected to manual gain. Manual gain setting values would never be reflected to the preset values. Preset values cannot be data saved. PresetGainX Magnification Decibel equivalent Gain_x1 Gain_x2 6.0dB Gain_x3 9.5dB Gain_x4 12.0dB Gain_x5 14.0dB Gain_x6 15.6dB Gain_x7 16.9dB Gain_x8 18.0dB ©2017 CIS Corporation. All rights reserved.

  • Page 18: Black Level Adjustment

    When Once of BalanceWhiteAuto is selected, white balance is automatically adjusted and the new Red gain and Blue gain shall be shown in BalanceRatioRed/BalanceRatioBlue. When 1.0 is set for both BalanceRatioRed and BalanceRatioBlue, white balance becomes invalid. ©2017 CIS Corporation. All rights reserved.

  • Page 19: Shading Correction

    Defective Pixels Correction □ Defective pixels correction at EX-Factory. CIS compensates the noticeable CMOS pixel defects found at the shipping inspection prior to our shipment. This function can be OFF. ※When ROI is set, defective pixels correction function becomes invalid.

  • Page 20: Noise Filter

    □ Camera settings shall be restored to the factory settings right after completion of UserSetDefault. However, there would be some cases that command indications are not updated depending on its indication software used. Please make sure to update the command. ©2017 CIS Corporation. All rights reserved.

  • Page 21: Factory Settings

    ExposureTime 33333.000 StrobeSelector NoStrobe StrobeActivation Positive StrobeDelay StrobeWidth Gain 1.000 BlackLevel BalanceWhiteAuto Only for color model. ShadingCorrection DefectivePixelCorrection ImpulseNoiseFilter ConnectionConfig CXP3_X4 ※ Factory setting values are the same as the one for UserSetDefault command. ©2017 CIS Corporation. All rights reserved.

  • Page 22: Dimensions

    VCC-120CXP1M/VCC-120CXP1R Preliminary Rev.905-0120-Z1 Dimensions 6.1. Camera Dimensions ©2017 CIS Corporation. All rights reserved.

  • Page 23: Optical Axis Accuracy

    VCC-120CXP1M/VCC-120CXP1R Preliminary Rev.905-0120-Z1 6.2. Optical Axis Accuracy ©2017 CIS Corporation. All rights reserved.

  • Page 24: Case For Indemity (Limited Warranty)

    CIS Corporation, at its option, repairs or replaces it at no charge to you. Products out of warranty period will be subject to charge. CIS repairs the products as long as it is repairable. CIS shall be exempted from taking responsibility and held harmless for damages or losses incurred by the following cases.
