AES 702/AB Installation Manual

1200 keypad manual
V1
Installation
Please read the entire instructions before installing.
Range test the system before installing items, or screwing items to walls,
otherwise your refund value will be affected due to items being marked or
not in new condition!
Fig.1.
150m
Typical
Entrance
Pillar
Transmitter / receiver - Keep
Speech
away from ground, as high as
Unit
possible. For best results, do
not install too close to sources
of electrical interference e.g.
gate automation panel
Wiring
Fig.2.
IMPORTANT:
Do NOT drill
Intercom
holes in the top
or near the top
Transmitter
of the enclosure.
Do NOT use
702
silicone
sealants!
Keep short as possible, 8 meters max
Antenna
Relay
time
jumper
Caution
DELETE
Code
SPK 3 2 1 12v
12v
out
in
+ -
-
- +
+
12-13v
d.c
Solid core of shield
connected to 0V on
PCB above for better
audio quality.
Relay time jumper
Jumper ON = 4 second pulse time.
Jumper OFF = Double pulse for strike lock.
Note: For keypad models, ensure to connect both the relays on the
keypad and the intercom transmitter to the lock or gate controller.
For magnetic locks, relays should be connected in series, normally
closed. For strike locks, relays should be connected in parallel,
normally open.
Installation Manual
702/AB & ABK Wireless Intercom System
House or
reception
area
For longer range
applications, locate the
handset near a window at
front of property.
Note: Wood and glass only
reduce signal strength by
10-20%. Masonry will reduce
signal strength by 20-50%
per wall. Metal can totally
block signals.
Remove only
the top screws
for access.
The front plate
is hinged and
will open
downwards.
Button 2
4
6
8
ac/dc
SPK
12v
vol
- + -
+
Relay output
N/C or N/O
Tamper
N/C
N/O
OUT3 COM
N/C
+ -
12-24v
OUT1 OUT2
dc
for
Handset
Notes
Once the system is installed and switched on, wait 30-60 seconds before
testing. The handsets should already be coded for you.
Press a call button and check the handset rings. The call can be
answered and pressing the lock release button should activate the relay
on the door controller.
Should the system not operate at the required range, try re-locating the
handset to a location which may have line of sight to the gate transmitter
through a window. Alternatively, a high gain antenna can be purchased
from your dealer to extend range.
Coding
Procedure 1 - Code handsets from scratch (for a button with no
working handsets already coded)
Should you need to code a handset to the system, follow this procedure..
1) Clear the code from the new handset by shorting the pads on the
back, near the power connections. The handset will bleep to confirm.
Press and hold the appropriate corresponding push button on the
Button 1
speech panel for more than 5 seconds. Once you begin to hear bleeping,
release the button.
2) Press and hold the unlock button on the handset until a bleep is heard
3
and release.
5
3) Both devices should play a short melody if the procedure was
successful.
7
Procedure 2 - Code an additional handset in an apartment (where a
handset already exists)
1) Clear the code from the new handset by shorting the pads on the
Single
button back, near the power connections. The handset will bleep to confirm.
2) Press and hold the unlock button on the new handset. After a few
seconds you will hear a bleep. Keep holding until you hear a second and
then a third, and release the button.
Shield can be
3) Press and hold the lock/unlock button on the existing working
connected to
handset until the second bleep is heard.
chassis
4) Both handsets should bleep with a confirm tone if successful.
INT Lock
5) Now you need to tell the additional handset that it is a different
O/P1 inhib
handset number to the first handset. To do this, press and hold both
Sense
buttons on the new handset until the first bleep is heard and release.
(-)GND
6) Then press the channel button once to select channel 2. Should you
DU out
be adding a third handset, you would press the channel button again to
K or A
select channel 3.
7) After a few seconds the procedure should be complete.
8) Press the call button on the intercom and check both handsets ring,
and that each can be answered and voice is working.
Note: If the coding procedure is not done correctly or fails, and the system
is not coded correctly, it is advised to completely delete all codes and start
again from scratch to code in the handsets. The overall procedure to do
this is as follows..
1) Press code button on the door / gate transmitter to delete the code on it.
2) Delete the code on all handsets by shorting the pads as described
above.
3) Code the first handset for each button as shown in procedure 1.
4) Code any additional slave handsets in each apartment as per procedure
2 shown above.
The handset can be desk top mounted or
wall mounted, and comes complete with
Power
a wall mounting bracket.
connection
Power is supplied by a 5v d.c. wall plug
(5v D.C)
adaptor.
Volume control is behind the handset for
Volume control
ringing volume.
(at rear)
This system is capable of supporting up
Door / gate
release
to 3 call buttons, and up to 3 handsets for
each call button, totalling 9 handsets
Channel button
overall.
