CIS VISION:mini VCC-G22S21ACL Product Specification & Operational Manual

Sxga b/w camera 49mhz pixel clock camera link
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
VCC-G22S21ACL
Rev.900-613-33
English
SXGA B/W Camera
49MHz Pixel Clock Camera Link
VCC-G22S21ACL
Product Specification
& Operational Manual
CIS Corporation
©2014 CIS Corporation. All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VISION:mini VCC-G22S21ACL and is the answer not in the manual?

Questions and answers

Related Manuals for CIS VISION:mini VCC-G22S21ACL

Summary of Contents for CIS VISION:mini VCC-G22S21ACL

  • Page 1 VCC-G22S21ACL Rev.900-613-33 English SXGA B/W Camera 49MHz Pixel Clock Camera Link VCC-G22S21ACL Product Specification & Operational Manual CIS Corporation ©2014 CIS Corporation. All rights reserved.

  • Page 2: Table Of Contents

    9. Initial Settings ................15 10. CCD Optical Axis Accuracy ..............16 11. Dimensions .................. 17 12. Cases for Indemnity (Limited Warranty) ............18 13. CCD Pixel Defect ................18 14. Product Support ................19 ©2014 CIS Corporation. All rights reserved.

  • Page 3: Scope Of Application

    AC leaks from the connected devices may cause damages or destroy the camera.  Do not apply excessive voltage. (Use only the specified voltage.) Unstable or improper power supply voltage may cause damages or malfunction of the camera. ©2014 CIS Corporation. All rights reserved.

  • Page 4: Product Outline

    Full frame scan mode and three different partial scan modes are available. □ Approx. 25 fps at full frame scan mode. □ Only 29mm cubic in size (excluding projection), light weight 50g, and speed makes it a best match for □ use in embedded systems. ©2014 CIS Corporation. All rights reserved.

  • Page 5: Specification

    OFF (1/25), 1/50, 1/100, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/10000, variable range 1/20000, 1/90000s ・Fixed Trigger Shutter Mode ・Pulse Width Trigger Shutter Mode Trigger shutter mode *Trigger pulse width shall be over 1H and less than 1/2s. ©2014 CIS Corporation. All rights reserved.
  • Page 6 Y, and ±Z, 6 directions. (without package) Temperature Operation guaranteed: -5℃～+45℃ Performance guaranteed: 0℃～+40℃ Operation environment RH 20～80% with no condensation Humidity Temperature -25℃ ～ +60℃ Storage environment RH 20～80% with no condensation Humidity ©2014 CIS Corporation. All rights reserved.

  • Page 7: Camera Output Signal Specification

    Digital 10bit : 3FFh output : 08 ± 03h Setup Level Digital 8bit signal : 020 ± 00Ch Digital 10bit 5 seconds shall be waited after turning on power to get proper camera operation. ©2014 CIS Corporation. All rights reserved.

  • Page 8: Ccd Spectral Response (Representative Value)

    VCC-G22S21ACL Rev.900-613-33 4.3. CCD Spectral Response (Representative value) ※ Lens characteristics and illuminant characteristics are not considered. ©2014 CIS Corporation. All rights reserved.

  • Page 9: Function Settings

    Shutter Speed = (1067.3-Data) x 36.46μs Max Data = 42Bh = 1067 Positive Input Trigger Polarity Negative Input Input Trigger Port Select 012 26pin Camera Link connector (12226-1100-00 PL) LVDS 6pin circular connector (HR10-7R-6PA) ©2014 CIS Corporation. All rights reserved.
  • Page 10 Re-triggering at H-Synchronous Mode shall be after 2H of CCD read out signal. Re-triggering at CLK-Synchronous Mode shall be after completion of video output. Trigger pulse width shall be within the range of over 1HD to less than 1/2 sec. ©2014 CIS Corporation. All rights reserved.

  • Page 11: External Connector Pin Assignment

    Do not connect 6.2. 26pins camera Link connector 12226-1100-00 PL (SUMITOMO 3M) Pin No. Pin No. Xclk- Xclk+ SerTC+ SerTC- SerTFG- SerTFG+ CC1- CC1+ (Trigger IN-) (Trigger IN+) CC2+ CC2- CC3- CC3+ CC4+ CC4- (GND) ©2014 CIS Corporation. All rights reserved.

  • Page 12: Timing Chart

    560 H 48 H 667 H Partial Scan Mode 3 65 H 410 H 63 H 547 H * Recommended numbers of output lines at full frame scan mode is 1024H dividing at the center. ©2014 CIS Corporation. All rights reserved.

  • Page 13: Trigger Shutter Mode

    Partial Scan Mode 3 65 H 410 H 63 H 547 H CLK- Synchronous Mode Details at Pulse Width Trigger Shutter Mode Trigger Input Signal Discharge Signal Read Out Signal Delay 7.53μS Delay 18.64μS Exposure Time ©2014 CIS Corporation. All rights reserved.

  • Page 14: Remote Interface Function

    (Reboot the camera, and the data is reset to the initial setting.) To save the data into EEPROM, please refer to Clause 5.4. Function Setting. Note: Once the data was saved into EEPROM, it may not be reset to t he initial settings. ©2014 CIS Corporation. All rights reserved.

  • Page 15: Initial Settings

    Manual Shutter Control 009&010 Invalid Trigger Polarity 0: Positive Input Input Trigger Port Select 0: 26 pins Camera Link connector (12226-1100-00 PL) Output Data Select 0:8bit Output Data Trigger Reset Mode 0: H-Synchronous Mode ©2014 CIS Corporation. All rights reserved.

  • Page 16: Ccd Optical Axis Accuracy

    Inclination of effective pixels θ to datum plane shall be The center of effective pixels shall θ ≦±0.5° be within Φ 0.6 to the center of lens mount. (＊) Dimension from datum plane to the center of lens mount. ©2014 CIS Corporation. All rights reserved.

  • Page 17: Dimensions

    VCC-G22S21ACL Rev.900-613-33 11. Dimensions ©2014 CIS Corporation. All rights reserved.

  • Page 18: Cases For Indemnity (Limited Warranty)

    CCD pixel defects might be noted with time of usage of the products. Cause of the CCD pixel defects is the characteristic phenomenon of CCD itself and CIS is exempted from taking any responsibilities for them. ©2014 CIS Corporation. All rights reserved.

  • Page 19: Product Support

    We shall be exempted from taking responsibility and held harmless for damage or malfunction of your hardware and software caused by using this control software. The purpose of this control software is for you to check operation and evaluate our products. Please be noted that CIS does not customize the program nor provide source code.
