- Page 1 ASENTO INSTALLATION MANUAL EV-BLZ19R CHEVROLET BLAZER 2019& UP PASSENGER SIDE...
- Page 2 1. Slack the front seat bolts. Remove the top and bottom rear seat bolts on both sides. Remove the lower brackets and plastic trims from the seat rail. Keep the OEM bolts for reinstallation of the ASENTO floor adapter. 2. Cut a notch in the carpet at the right hand seat mount to facilitate the installation of the floor bracket.
- Page 3 3. Install the ASENTO floor adapter # EV-ACA17R-01 using the OEM bolts. 4. Remove the lower b pillar trim.
- Page 4 5. Remove the upper b pillar trim. 6. Install the b pillar adapter # EV-BLZ19R-02 to the b pillar using the eight provided pop rivets. (NOTE: drill slowly high strength steel)Then install the pointed allen screw into the b pillar adapter.
- Page 5 7. A ¾ inch hole will have to be drilled in both the top and bottom b pillar trims to be able to bolt the ASENTO to the b pillar bracket. The plastic stopper on the upper b pillar trim will have to be removed.
- Page 6 10. The lower b pillar trim will have to be modified to allow clearance for the ASENTO. Use the provided stencil to cut out the hole. Now install the lower trim and mark the hole to be drilled, reinstall the rims and remove the pointed allen screw.
- Page 7 11. On vehicles with a manual seat the recline lever will have to be replaced with the one provided # EV- TER18R-03 and the seat belt retention elastic installed to hold the seat belt in place.
- Page 8 12. Install the ASENTO to the floor adapter and b pillar adapter. Use the 3/8-16x1’’ bolt and flat washer at the floor adapter and the 3/8-16x1’’1/4 bolt and flat washer at the b pillar.
- Page 9 13. Connect the ASENTO control box to the ASENTO. Connect the control box to the pendant and to the 12 volt power supply. Then attach the control box under the seat in a place where it cannot be damaged by the seat moving. Place the hand pendant in a place convenient to the client. NOTE: Once the 12 volt power is connected the ASENTO will beep to signify that it is ready to be programed.
- Page 10 15. Install the transfer board by sliding it onto the chrome shaft of the ASENTO. Make sure that it slides all the way onto the shaft. Final Inspection Make sure all bolts are all properly fastened. Make sure that ASENTO works well with and without a passenger. ...
- Page 11 ELECTRICAL INSTALLATION FOR ASENTO 1. Thread the lead power cable (red +) under the doorstep moulding and through the firewall. WARNING: Pass through a grommet in the firewall to prevent the cable from chaffing. 2. Install the circuit breaker near the battery and then connect the battery to the circuit breaker.
- Page 12 ELECTRICAL BOX CONNECTIONS ASENTO...
- Page 13 ASENTO WITH SPEEDY LIFT...
-
Page 14: Warning Decals
WARNING DECALS After completing the installation of the ASENTO, please take time to install the warning decals. NOTE: The surface must be clean, dry and at ambient temperature for the sticker to stick to the surface. Start by locating a position to install the decals. ... - Page 15 During the first year of the warranty, Adapt Solutions will supply the replacement parts as well as a pre-set monetary amount (determined by Adapt Solutions) for the repair if a defect in materiel or workmanship is discovered. After the initial year of this warranty, only parts and components are covered.
