- Page 1 POWER-PULL INSTALLATION MANUAL -SIDE ENTRY-...
- Page 2 WARNING: THE POWER-PULL SHOULD NEVER BE USED AS A TIE DOWN FOR THE WHEELCHAIR. WARNING: THE POWER-PULL UNIT MUST BE INSTALLED FLAT. NEVER ON IT’S SIDE. WARNING: WHEN PLACING THE UNIT BEHIND THE SEAT MAKE SURE THAT THE CABLE HOUSING IS NOT TWISTED,...
- Page 3 NOTE: The POWER-PULL box can also be installed in the rear of the vehicle with the cable coming in a straight line from behind the seat.
- Page 4 2. Position the pulley assembly as shown in the pictures below. Note: The pulley assembly must be above the floor level around the approximate height where the in-out cable hooks onto the chair. The pulley assembly will have to be adapted to different types of vehicle interiors with custom, in- house made brackets.
- Page 5 -The 15 amp breaker is for use when the combined weight of the client and chair is above 250 lbs. 4. Connect the power cable (red+) and the ground cable (black -) to the POWER-PULL power supply cables coming out of the POWER-PULL box.
- Page 6 Now, place the cable and straps onto the hook on the ramp. WARNING: When the POWER-PULL is not in use, the unit must always be in the RELEASE mode with the cable hooked onto the ramp to prevent damage to the cable, straps and hook.
- Page 7 During the first year of the warranty, Adapt Solutions will supply the replacement parts as well as a pre- set monetary amount (determined by Adapt Solutions) for the repair if a defect in materiel or workmanship is discovered.
