- Page 1 ASENTO INST AL L AT IO N MANUAL EV- EXP18R FORD EXPEDITION 2018 & UP PASSENGER SIDE POWER SEAT...
- Page 2 Electrical Kit EV-EXP18R-00 Installation Kit -Right- EV-EXP18R-06 Seat Switch Support -Right- EV-EXP18RB-07 Seat Trim -Right- Black EV-EXP18-08B Electric Control Hole Cover -Black- PART NUMBER EV-EXP18R DESCRIPTION ASENTO Ford Expedition 2018 & Up -Right- 1 of 5 |tech@adaptsolutions.ca|866.641.0419|418.889.9838 fax ADAPT SOLUTIONS...
- Page 3 Socket Head Cap Screw Zinc Plated 1/4-20 UNC x 7/8" PRD 338-169P Flat Head Socket Cap Screw Zinc Plated 1/4-20 x 1 ,250 PART NUMBER EV-EXP18R DESCRIPTION ASENTO Ford Expedition 2018 & Up -Right- 2 of 5 |tech@adaptsolutions.ca|866.641.0419|418.889.9838 fax ADAPT SOLUTIONS...
- Page 4 Flat Washer Zinc Plated I.D. 3/16 USS PRD 400-289 Nylon Insert Locknut Stainless 10-24 PRD 400-583 Pan Head Machine Screw Phillips Stainless 10-24 x 5/8 PART NUMBER EV-EXP18R DESCRIPTION ASENTO Ford Expedition 2018 & Up -Right- 3 of 5 |tech@adaptsolutions.ca|866.641.0419|418.889.9838 fax ADAPT SOLUTIONS...
- Page 5 PRD 337-235 Socket Head Cap Screw 3/8-16 UNC x 1 ¼ SN 190-025 Binder Slot Head Post & Screw Black ,250 x ½"Lg PART NUMBER EV-EXP18R DESCRIPTION ASENTO Ford Expedition 2018 & Up -Right- 4 of 5 |tech@adaptsolutions.ca|866.641.0419|418.889.9838 fax ADAPT SOLUTIONS...
- Page 6 U-EV-UNI-01 Machined Socket Shoulder Screw PRD 333-107M Nylon Insert Locknut 5/16-18 Thin EV400-01R Transfert Platform -Right- XLS430B-01R Transfer Plate Cushion -Right- Black PART NUMBER EV-EXP18R DESCRIPTION ASENTO Ford Expedition 2018 & Up -Right- 5 of 5 |tech@adaptsolutions.ca|866.641.0419|418.889.9838 fax ADAPT SOLUTIONS...
- Page 7 Po we r se a t b utto ns re lo c a te d to the fro nt o f the se a t he ig ht a nd insta lla tio n time . EST IMAT ED ADAPT SOLUTIONS 11-2020...
- Page 8 1. Remove the lower b-pillar trim. To do this, first, remove the rocker panel trims adjacent the front passenger and mid-row passenger’s doors. Also, remove the seat belt.
- Page 9 2. Install the b pillar adapter ( EV-EXP18R-02) to the b pillar using the eight (8) provided pop rivets and then install the pointed allen screw into the b pillar adapter. NOTE: Drill slowly through the high strength steel using a 3/16 drill bit. 3.
- Page 10 4. Run the power from the battery to the ASENTO. To do this, thread the red power cable (+) under the doorstep moulding and through the firewall. Make sure you pass through a grommet in the firewall to prevent the cable from chaffing. Install the circuit breaker near the battery and then connect the battery to the circuit breaker.
- Page 11 6. Remove the bolt holding the seat belt roller, and install the ASENTO floor adapter ( EV-EXP18R-01) use the two provided 10x1.5x40 mm bolts for the seat belt roller, and to bolt the floor bracket to the b pillar. Use the OEM bolt at the seat floor mounting point. 7.
- Page 12 8. The lower part of the b pillar trim will have to be modified using the provided stencils to cut and remove some parts to allow fitment of the ASENTO. Also, remove the rubber seat belt cover and install the provided plug into the hole.
- Page 13 9. Reinstall the trim.
- Page 14 10. Remove the right hand side seat trim. Unclip the seat trim wire at the front. 11. Remove the seat control switch module from the trim and install the provided blanc to cover the holes. Use the provided metal clips to hold in place. NOTE: The switches will be relocated to the front of the seat.
- Page 15 12. The seat trim will have to be cut and modified, and the provided replacement trim ( EV-EXP18RB-07) installed onto the seat trim. Mark and cut as per the photos.
- Page 16 13. Install the provided trim onto the seat trim, drill out the holes and install the five trim clips, cut of the point of the trim clips once installed. 14. Install the seat switch control module onto the provided adapter ( EV-EXP18R-06) using the four provided machine screws and lock nuts.
- Page 17 16. Install the seat switch bracket ( EV-EXP18R-06) at the front of the seat, use the two provided trim clips to push into the corresponding holes on the seat base pan. Use zip ties run around he round bar and through the holes on the seat switch bracket and at the same time hold the wring from the connector.
- Page 18 18. Install the ASENTO to the floor bracket using the 3/8X16X1’’1/4 bolt and to the b pillar using the 3/8 button head bolts and adapter ( EV-EXP18R-04). 19. Slide the seat belt pre-tensioner into the slot on the floor bracket and reconnect, attach the wire to the floor bracket with a zip tie.
- Page 19 20. Install the rubber seat belt protector removed from the b pillar trim and install it on to the seat belt bracket ( EV-EXP18R-03). Mount the bracket on to the floor bracket and pre-tensioner. Use the OEM bolt and the 10mm nut provided. Reattach the seat belt, attach the rubber with zip ties. 21.
- Page 20 22. Install the security handle using the provided shoulder bolt and nut. 23. Connect the ASENTO control box to the ASENTO . Connect the control box to the pendant and to the 12-volt power supply. Then attach the control box under the seat in a place where it cannot be damaged by the movements of the seat.
-
Page 21: Final Inspection
The ASENTO will now leave reduced power mode and be fully functional. NOTE: there is a programing video available on the Adapt Solutions website in the Dealers / Resources/ ASENTO section. Final Inspection ... - Page 22 ECTRICAL BOX CONNECTIONS ASENTO...
- Page 23 ASENTO WIT H SPEEDY-LIFT...
-
Page 24: Warning Decals
WARNING DECALS After completing the installation of the ASENTO, please take time to install the warning decals. NOTE: The surface must be clean, dry and at ambient temperature for the sticker to stick to the surface. Start by locating a position to install the decals. ... - Page 25 ADAPT-SOLUTIONS #1 LTD 3 YEAR L IMIT ED WARRANT Y XL-BASE, XL-SEAT, ASENTO, HI-LIFT, SPEEDY-LIFT, XL-BOARD, POWER-PULL Ad a p t-So lutio ns # 1 Ltd . (Ad a p t So lutio ns), wa rra nts to the o rig ina l p urc ha se r o f a XL-BASE, XL-SEAT, ASENTO, HI- LIFT, SPEEDY-LIFT, XL-BOARD o r a POWER-PULL tha t the e q uip me nt is fre e fro m d e fe c ts in ma te ria l a nd wo rkma nship fo r a p e rio d o f thre e ye a rs fro m d a te o f p urc ha se .
