- Page 1 ASENTO INSTALLATION MANUAL EV-COLC15R CHEVROLET COLORADO/ GMC CANYON CREW CAB 2015 & UP PASSENGER SIDE...
- Page 2 Transfer Plate Cushion -Right- Black EV600B-01 Pillar Trim -Black- EV700-AL Electrical Kit EV-COLC15R-00 Installation Kit -Right- EV-COLC15B-04 Floor Cover -Black- EV-COLC15RB-05 Seat Trim -Right- Black PART NUMBER EV-COLC15R DESCRIPTION Chevrolet Colorado ASENTO -Right- 1 of 6 SCALE 1:6 |tech@adaptsolutions.ca|866.641.0419|418.889.9838 fax ADAPT SOLUTIONS...
- Page 3 Flat Washer Zinc Plated I.D. 3/8 USS PRD BTT66 Button Head Stainless 3/16 x 9/16 EV-COLC15B-04 Floor Cover -Black- EV-COLC15RB-05 Seat Trim -Right- Black PART NUMBER EV-COLC15R DESCRIPTION Chevrolet Colorado ASENTO -Right- 2 of 6 |tech@adaptsolutions.ca|866.641.0419|418.889.9838 fax ADAPT SOLUTIONS SCALE 1:6...
- Page 4 Socket Head Cap Screw Zinc Plated 1/4-20 UNC x 7/8" PRD 338-169P Flat Head Socket Cap Screw Zinc Plated 1/4-20 x 1 SCALE 1:4 SCALE 1:3 PART NUMBER EV-COLC15R DESCRIPTION SCALE 1:4 3 of 6 Chevrolet Colorado ASENTO -Right- |tech@adaptsolutions.ca|866.641.0419|418.889.9838 fax ADAPT SOLUTIONS...
- Page 5 Flat Washer Zinc Plated I.D. 3/8 USS PRD 400-289 Nylon Insert Locknut Stainless 10-24 PRD 400-583 Pan Head Machine Screw Phillips Stainless 10-24 x 5/8 PART NUMBER EV-COLC15R DESCRIPTION 4 of 6 Chevrolet Colorado ASENTO -Right- SCALE 1:4 |tech@adaptsolutions.ca|866.641.0419|418.889.9838 fax ADAPT SOLUTIONS...
- Page 6 Hex Cap Bolt Zinc Plated 3/8-16 x 1 G5 PRD 341-108P Flat Washer Zinc Plated I.D. 3/8 USS PRD BTT66 Button Head Stainless 3/16 x 9/16 PART NUMBER EV-COLC15R DESCRIPTION 5 of 6 Chevrolet Colorado ASENTO -Right- SCALE 1:3 |tech@adaptsolutions.ca|866.641.0419|418.889.9838 fax ADAPT SOLUTIONS...
- Page 7 Safety Arm -Right- EV400-01R Transfert Platform -Right- XLS430B-01R Transfer Plate Cushion -Right- Black U-EV-UNI-01 Machined Socket Shoulder Screw PRD 333-107M Nylon Insert Locknut 5/16-18 Thin PART NUMBER EV-COLC15R DESCRIPTION 6 of 6 Chevrolet Colorado ASENTO -Right- SCALE 1:5 |tech@adaptsolutions.ca|866.641.0419|418.889.9838 fax ADAPT SOLUTIONS...
- Page 8 1. The first step of the installation will be to remove the left hand side plastic seat trim.
- Page 9 2. The plastic trim will have to be modified to allow clearance for the ASENTO. Cut along the red doted lines. Then reinstall the trim. 3. Drill a ¼-inch hole in the trim support, then install the provided seat trim # EV-COLC15L-05 with the provided Christmas tree and the self-tapping screw at the back.
- Page 10 4. Remove the b pillar trim. 5. Remove the seat belt tensioner bolt.
- Page 11 6. Remove the rear seat bolt mounting bolts. 7. Install the b pillar adapter # EV-COLC15R-02 by drilling the corresponding holes and fixing with the provided 3/16 x 11/16 pop rivets. 8. Remove the top halve of the b pillar trim from the bottom halve.
- Page 12 9. The lower half of the b pillar trim will have to be modified to allow the ASENTO to fit. Cut out a notch at the bottom of the b pillar. Follow the measurements and the provided stencil. 2 inches 91/2 inches 5/8 inches...
- Page 13 10. Install the provided pointed allen screw into the threaded hole on the b-pillar adapter. Take the b- pillar trim, install it onto the b-pillar and tap it onto the pointed allen screw to mark the point that the b-pillar will have to be drilled and then remove the allen screw. A 3/4 hole will have to be drilled to allow the b pillar adapter to pass through the plastic.
- Page 14 13. Install the provided fabric cover # EV-COLC15B-04. Line up the two holes with the rear seat mounting. 14. Install the ASENTO floor adapter bracket # EV-COLC15R-01 using the OEM bolts.
- Page 15 15. Reinstall the b pillar trim. 16. Install the ASENTO using the 3/8x1’’1/4 bolt and nut at the bottom and the # EV- COLC15R-02 b pillar bracket with 3/8x3/4 bolt and the 3/8x1’’bolt.
- Page 16 17. Connect the ASENTO control box to the ASENTO. Connect the control box to the pendant and to the 12-volt power supply. Then attach the control box under the seat in a place where it cannot be damaged by the seat moving. Place the hand pendant in a place convenient to the client.
- Page 17 19. Install the transfer board by sliding it onto the chrome shaft of the ASENTO. Make sure that it slides all the way onto the shaft. Final Inspection: Make sure all bolts are all properly fastened. Make sure that ASENTO works well with and without a passenger. ...
- Page 18 ELECTRICAL INSTALLATION FOR ASENTO 1. Thread the lead power cable (red +) under the doorstep molding and through the firewall. WARNING: Pass through a grommet in the firewall to prevent the cable from chaffing. 2. Install the circuit breaker near the battery and then connect the battery to the circuit breaker.
- Page 19 ELECTRICAL BOX CONNECTIONS ASENTO...
- Page 20 ASENTO WITH SPEEDY LIFT...
-
Page 21: Warning Decals
WARNING DECALS After completing the installation of the EVOLVE, please take time to install the warning decals. NOTE: The surface must be clean, dry and at ambient temperature for the sticker to stick to the surface. Start by locating a position to install the decals. ... - Page 22 During the first year of the warranty, Adapt Solutions will supply the replacement parts as well as a pre-set monetary amount (determined by Adapt Solutions) for the repair if a defect in materiel or workmanship is discovered. After the initial year of this warranty, only parts and components are covered.
