Introduction
The STR7/9 USB developer kit is a complete firmware and software package including
examples and demos for all USB transfer types (control, interrupt, bulk and isochronous). It
supports all ST 32-bit USB microcontrollers (STR71x, STR75x and STR91x).
The aim of the STR7/9 USB developer kit is to use the same certified USB library across the
STR7/STR9 microcontroller families and present for each at least one firmware demo per
USB transfer type.
This document presents a description of all the components of the STR7/9 USB Developer
kit, including:
■
Common STR7/9 USB library: All processes related to default endpoint and standard
requests
■
Joystick mouse demo: Interrupt transfer
■
Custom HID: interrupt transfer
■
Device Firmware Upgrade (DFU): control transfer
■
Mass storage demo: Bulk transfer
■
Virtual COM port: Bulk transfer
■
USB voice demo (speaker and microphone): Isochronous transfer
November 2008
STR7/STR9 USB developer kit
Rev 2
UM0290
User manual
www.st.com
1/76
