2 Specifications

2.1 Inputs

Item
Temperature Display Range
Temperature Display Resolution
Temperature Accuracy
Setpoint Range
Remote Temperature Sensor
Energy Savings Input (ESI)

2.2 Outputs

Item
Relay Outputs
Analog Output
Contact Rating
Minimum contact life

2.3 Communication

Item
Protocol Compliance
Physical Layer
Cabling
Authentication

2.4 Electrical

Item
Supply Voltage and Current
Power Source Class
Internal Power Supply
UM-15095500-AA0
14 to 140°F (-10 to +60°C)
0.1°F (0.1°C)
±1.8°F (±1.0°C) with all outputs off
32-122°F (0-60°C) in 0.5° (°F or °C) increments
Provision for NTC Type 3kΩ thermistor
'Dry' contact closure for occupancy control
C/H Stage1, C/H Stage 2, Fan
Single 0-10Vdc control output (C/H)
SPST 2A at 30 VAC with inductive load
100,000 cycles
BACnet/IP with B-ASC, BTL Listed
802.11 b/g/n Wi-Fi network
None
WPA2-PSK(AES)
24 VAC (±10%) 5 VA
NFPA 70 (NEC) Article 725 Part III Class 2
Half-wave rectified and filtered DC
Description
Description
Description
Description
