Object name
Modulating/floating
Control Out
AV 19
Percentage
Device Instance
UDP Port No
Humidity Offset
Cooling Short Cycle
Delay
Cooling Maximum
Cycles per Hour
Heating Short Cycle
Heating
Maximum Cycles
per Hour
Analog Minimum
Output for AO2
Span Offset for
AO2
Heartbeat Rate
CO2 Input High
CO2 Control Out
Proportional Band
CO2 Setpoint
CO2 Control
Minimum Out
Percentage
After Hour Extension
Run Time
Control Valve
Feedback Input Low AV 35
Control Valve
Feedback Input High AV 36
Options
Analog Input High
UM-15095500-AA0
Type & Readable/
Instance Writable
R/W
AV 20 R/W
AV 21 R/W
AV 22 R/W
AV 23 R/W
AV 24 R/W
AV 25 R/W
AV 26 R/W
AV 27 R/W
AV 28 R/W
AV 29 R/W
AV 30 R/W
AV 31 R/W
AV 32 R/W
AV 33 R/W
AV 34 R/W
R/W
R/W
AV 37 R/W
AV 38 R/W
Description
Percentage of Modulating/
Floating Control Output
Device Instance
UDP Port Number
Humidity Offset Value
(221CH models only)
Cooling Short Cycle Delay
Cooling Maximum Cycles
per Hour
Heating Short Cycle Delay
Heating Maximum Cycles
per Hour
Minimum Output Voltage in
Digital Value When Reach
Low Limit for AO2
Span Offset for AO2
Communication Heartbeat
Minimum Rate
CO2 Input High Value
CO2 Control Output
Proportional Band
CO2 Setpoint
CO2 Control Minimum
Output Percentage
After Hour Extension Run
Time
Input Low Value of Control
Valve Feedback
Input High Value of Control
Valve Feedback
Options (mode reset)
Analog Input High Value
Range and Definition
0～100 (0%～100%)
0~4194302
(NOTE: Changing this value
needs to unlock modification
for communication
parameters in advance.
i.e. AV17=0~255 or
512~768. Please refer to
LOCK(AV17) for details)
0~65535
-300~300 (-30.0～30.0
%RH)
1~3 Minutes
2~6 Cycles
0~3 Minutes
2~6 Cycles
0~125 (LSB)
-55~0 (LSB)
10~3600 s
1000~3000 ppm
100~2000 ppm
600~1000 ppm
0~20%
5~20(0.5~2.0) Hour
0~1000 (0.0～100.0 %)
0~1000 (0.0～100.0 %)
0-1 0:disable
1: enable
0~1000 (0.0～100.0 %)
