Contemporary Controls BASstat Series User Manual page 22

Item Mnemonic
E30 tyPE
Control Type
E31 OPL2 Minimum Output for AO2 (not used)
E32 SPA2 Span Offset for AO2 (not used)
E33 Hrtr Communication Heartbeat Minimum Rate
E34 CO2H CO2 Input High Value (not used)
E35 C2PB CO2 Control Output Proportional
Band (not used)
E36 C2SP CO2 Setpoint (not used)
E37 C2Lo CO2 Control Minimum Output (not used)
E38 AFtH After Hour Extension Time (not used)
E39 VALL Input Low Value of Valve Feedback
(not used)
E40 VALH Input High Value of Valve Feedback
(not used)
E41 OPts Options (mode change enable)
E42 AI-H Analog Input High Value (not used)
E43 Hrt Communication Heartbeat Flip-Flop
E44 CSPL Minimum Cooling Temperature Setpoint
E45 HSPH Maximum Heating Temperature Setpoint
E46 nFAn Minimum Fan Output (not used)
E47 hFAn Maximum Fan Output (not used)
E48 FAnL Low Fan Speed Setting (not used)
E49 FAn2 Med. Fan Speed Setting (not used)
E50 FAnH Hi Fan Speed Setting (not used)
E51 Run Modulating Fan Speed Run Type
(not used)
E52 OFFt Minimum Off Time
E53 On-t Minimum On Time
E54 Str Floating Motor Full Stroke Time (not used)
E55 Phy1 MAC address 1st & 2nd bytes
E56 Phy2 MAC address 3rd & 4th bytes
UM-15095500-AA0
Description
°C Scale
Default Range
4 4
60 10~3600
0 0/1
0 0/1
18.0 0.0-50.0
25.0 0.0-50.0
180 0~600 180
0 0~600 0
hhhh
hhhh
°F Scale
Default Range
0: Cooling Only
1: C&H Manual
4 4
2: C&H Auto
3: Heating Only
4: Single Mode
60 10~3600 10s
0 0/1 0: locked
1: unlocked
0 0/1 0: Off
65.0 32.0-122.0 0.1 (°C/°F)
77.0 32.0-122.0 0.1 (°C/°F)
0~600
5 (seconds)
0~600
5 (seconds)
hhhh
h: 0~F in hex
hhhh
h: 0~F in hex
Page 22
Step
1: On
