4 Operation

4.1 User Mode

User-side control is accomplished with six buttons – MODE (Heat/Cool, or Ventilate), FAN (Auto
or Continuous), UP, DOWN, SET, and POWER. There are also options to lock select buttons or
all buttons on the thermostat to limit user access if so required. A large LCD display indicates
setpoint, space temperature, occupancy status, and current mode of operation using graphical
icons.
System modes (Cool only, Heat only, Ventilate) available to the installer are dependent on
control type chosen from BACnet object [MSV1] Control Type or by toggling the MODE button
within one minute after setting an option command (OPTS) in the Engineering Menu. (See
section 4.2 Control Type of this manual). Once the operating mode (Heat only or Cool only) is
set by the installer, the BASstat will stay in that mode exclusively until a two-step control
changeover sequence is initiated. NOTE: a factory reset (rSt) will not change the operating
mode.
System modes and button operation may be limited by the installer, especially if the thermostat
is completely controlled over BACnet network.
The first tier of operation includes the following settings as shown below. To operate the
thermostat:
1. The POWER button
thermostat outputs. Turning the unit off with this button will disable the control outputs.
(ON/OFF control can be accomplished over BACnet as well).
2. At power ON, press any button to start the User Mode operation. Press the MODE button
to toggle between heat/cool mode or ventilation only mode.
Press the UP/ DOWN buttons
setpoint or rotate the values of a setting. Press the FAN button
modes of AUTO or CONTINUOUS. If no AUTO icon is displayed, the fan is in
CONTINUOUS mode and it will run continuously until commanded off using the FAN
button on thermostat or setting a BACnet command. If AUTO icon is flashing, the fan
is operating under delay timer and will shut off automatically when delay timer expires.
Press the SET button
toggle the unit between Occupied or Unoccupied states when outside of scheduled
operation. Use SET or MODE to apply (SET button can be locked in applications
forbidding occupancy state user control).
3. The thermostat will exit the Engineering Menu and return to its normal operating display 10
seconds after the last panel button press.
