BACnet Object Table - Wi-Fi Model (BACnet/IP)

Object name
BACnet Thermostat
Type &
Object name
Instance
Current
AI 0
Temperature
Active Temperature
AI 1
Setpoint
Built-in
Temperature
AI 2
Sensor
Remote
Temperature
AI 3
Sensor
Current Humidity
AI 4
UM-15095500-AA0
Type & Instance
Device 700001
Readable/
Writable
R
R
R
R
R
Object Property
(Readable/Writable)
Model Name (R)
Application Software Version (R)
Object Identifier (R)
Object Name (R/W)
Description
Current Temperature
Active Temperature Set-
Point
Built-in Temperature
Sensor Reading
Remote Temperature
Sensor Reading
Current Humidity (221CH
models only)
Range
32 characters (max.)
Range and Definition
-999~9999: -99.9〜999.9
℃/°F
°C :0~500 (0.0〜50.0℃)
°F : 320~1220
(32.0~122.0°F)
-999~9999:-99.9〜999.9
℃/°F
-999~9999:-99.9〜999.9
℃/°F
0~1000: 0.0〜100.0%RH
Page 31
