Contemporary Controls BASstat Series User Manual page 21

Item Mnemonic
E13 ESI ESI (DI1) digital sensor contact definition
E14 rE-C
Modulating Cooling direct/ reverse signal
output
E15 rE-H
Modulating Heating direct/ reverse signal
output
Space Temperature Source
E16 rS
Display present temperature value of or
current set-point for LCD
E17 -SP-
E18 door Door or Windows contact definition (not
applicable to all models)
E19 LFAn Lowest Fan speed in Auto fan mode
E20 Pct Output Percentage (not used)
E21 devH Device instance no. - Hi bytes
E22 devL Device instance no. - Low bytes
E23 UdP
UDP Port Number
E24 rHSt Relative Humidity Offset (221CH models
only)
E25 F-Ht Fan Output for Heating
E26 dLyC Cooling Short Cycle Delay
Cooling Maximum Cycles per
E27 cycC
Hour
E28 dLyH
Heating Short Cycle
Heating Maximum Cycles per
E29 cycH
Hour
UM-15095500-AA0
Description
°C Scale
Default Range Default
0 0~1
0 0~1
0 0~1
0 0~2
0 0~1
0 0~1
0
0~1
0 0~100
100 0~4194
0~999
(if ID-H
<=4193)
1 0~302
(if ID-H
= 4194)
0~65535
47808 47808
(BAC0) (BAC0)
(0~FFFF)
0 -30.0～
30.0
0
0/1
3 1~3
4 2~6
3 0~3
4 2~6
°F Scale
Step
Range
0: N.O.
0 0~1
1: N.C.
0 0~1
0: (Direct)
1: (Reverse)
0 0~1
0: (Direct)
1: (Reverse)
0: built-in
1: remote sense
0 0~2
2: assigned
through
BACnet
0: display PV
0 0~1
1: display SP
0: N.O.
0 0~1
1: N.C.
0: stop
0
1: low
0~1
0 0~100 1%
100 0~4194 1
0~999
(if ID-H
<=4193)
1 0~302 1
(if ID-H
= 4194)
0~65535
1
(0~FFFF)
0 0.1%RH
-30.0〜30.0
0: Disable
0 0/1
1: Enable
1 (minutes)
3 1~3
1 (cycles/hour)
4 2~6
1 (minutes)
3 0~3
1 (cycles/hour)
4 2~6
Page 21
