2 Specifications

2.1. Inputs

Item
Temperature Display Range
Temperature Display Resolution
Temperature Accuracy
Setpoint Range
Remote Temperature Sensor

2.2. Outputs

Item
Relay Outputs
Contact Rating
Minimum contact life

2.3. Communication

Item
Protocol Compliance
Physical Layer
Baud Rate
Cabling

2.4. Electrical

Item
Supply Voltage and Current
Power Source Class
Internal Power Supply
UM-15090000-AA8
14 to 140°F (-10 to +60°C)
0.1°F (0.1°C)
±1.8°F (±1.0°C) with all outputs off
32 to 122°F (0 to 50°C) in 0.5° (°F or °C) increments
Provision for NTC Type 3kΩ thermistor
Heating 1, Heating 2, Cooling 1, Cooling 2, Fan
SPST 2A at 30 VAC with inductive load
100,000 cycles
BACnet MS/TP with B-ASC, BTL Listed
2-wire, non-isolated EIA-485, no built-in EOL termination
9.6, 19.2, 38.4, 76.8 kbps (default 38.4 kbps), N81 format
Single-pair twisted 24GA with shield
24 VAC (±10%) 5 VA
NFPA 70 (NEC) Article 725 Part III Class 2
Half-wave rectified and filtered DC
Description
Description
Description
Description
