User Manual
4K 17" Display
3840 x 2160 native resolution / Display port 1.2 video input
1920 x 1080 & 1920 x 1200 resolution support
RMD-X3K3
Triple display drawer
RMD-17K-2L
Dual display drawer
RMD-17K-2R
Dual display drawer
19" 4:3 Display
1280 x 1024 native resolution / DVI-D + VGA video input
RMD-19-3
Triple display drawer
RMD-19-2L
Dual display drawer
RMD-19-2R
Dual display drawer
UM-CV-751-RMD-Q318V1
dedicated KVM switch and rackmount screen technology
2U Multi-Display Drawer
RMD-F17-3
RMD-F17-2L
( LH mounted )
RMD-F17-2R
( RH mounted )
( LH mounted )
( RH mounted )
FHD 17" Display
1920 x 1080 native resolution / DVI-D + VGA video input
Triple display drawer
Dual display drawer
Dual display drawer
www.rackmountsales.com
( LH mounted )
( RH mounted )
751
Advertisement
Related Manuals for CyberView RMD-X3K3
Summary of Contents for CyberView RMD-X3K3
- Page 1 FHD 17" Display 3840 x 2160 native resolution / Display port 1.2 video input 1920 x 1080 native resolution / DVI-D + VGA video input 1920 x 1080 & 1920 x 1200 resolution support RMD-X3K3 RMD-F17-3 Triple display drawer Triple display drawer...
- Page 2 Legal Information First English printing, January 2018 Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents. The information in this document is subject to change without notice. We are not liable for any injury or loss that results from the use of this equipment.
- Page 3 Contents < Part. 1 > Package Content P.1 - 3 Structure Diagram & Dimension P.5 - 8 Installation P.10 - 11 Connection Specifi cations / OSD < Part. 2 > Product Specifi cations P.12 - 15 On-screen Display Operation ( OSD ) P.17 - 20 <...
- Page 4 Before Installation ■ It is very important to mount the equipment in a suitable cabinet or on a stable surface. ■ Make sure the place has a good ventilation, is out of direct sunlight, away from sources of excessive dust, dirt, heat, water, moisture and vibration. Unpacking The equipment comes with the standard parts shown in package content.
- Page 5 < Part 1 > < 1.1 > Package Content RMD-X3K3 unit X 1 RMD-F17-3 / RMD-19-3 unit X 1 - 6ft DP cable X 2 or 3 - 6ft DVI cable X 2 or 3 - Power adapter & Power cord X 1 - Power adapter &...
- Page 6 < 1.2 > RMD-X3K3 / RMD-F17-3 Dimension 1mm = 0.03937 inch Front View Triple display RMD-X3K3 RMD-F17-3 Dual display ( LH mounted ) Dual display ( RH mounted ) Rear View RMD-X3K3 RMD-F17-3 Power DVI-D Power Central Central Left Left...
- Page 7 < 1.2 > RMD-19 Dimension 1mm = 0.03937 inch Front View Triple display RMD-19-2R Dual display ( LH mounted ) Dual display ( RH mounted ) Rear View DVI-D Power Central Left Right Side View Top View Product Dimension Packing Dimension Gross Model Display...
- Page 8 Intentionally Left Blank UM-CV-751-RMD-Q318V1 www.rackmountsales.com...
- Page 9 < 1.3 > Installation - How to install Installation Slides Step ■ The left and right rear mounting brackets are attached to the Multi-display drawer. Step ■ Measure the depth of the front and rear mounting rails. ■ Align each rear mounting bracket to a suitable length. ■...
- Page 10 < 1.3 > Installation - How to Use the Multi-Display Drawer Step ■ Unlock the key cylinder to 3 o’clock direction. Step ■ Hold the handle and slide out the drawer. Step Step ■ Flip up the LCD to a suitable angle. Step ■...
- Page 11 < 1.3 > Installation - How to Use the Multi-Display Drawer Step ■ Operate the multi-display drawer. Step ■ Close the Left Right display. ■ Flip down the LCD completely. Step Step ■ Must completely extend the drawer before returning it to the park position. ■...
- Page 12 < 1.3 > Installation - How to Use the Slides Figure 1. ■ A purple release button is located on the front of the slide. ( shown in Figure 1 ). ■ Figure 2. Pull and hold both side release buttons when pushing the Multi display drawer back to the rack.
- Page 13 Intentionally Left Blank UM-CV-751-RMD-Q318V1 www.rackmountsales.com...
- Page 14 < 1.4 > RMD-X3K3 connection DP Server RMD-X3K3 Multi-display Console Drawer Power Central Left Right DP cable x 2 or 3 DP server * DP cable x 2 for dual display Caution : The LCD drawer is hot-pluggable, but components of connected devices, such as the servers and KVM switch, may not be hot-pluggable.
- Page 15 < 1.4 > RMD-F17-3/RMD-19-3 connection USB Server RMD-F17-3 Mult-display Console Drawer RMD-19-3 DVI-D Power Central Left Right DVI cable x 2 or 3 USB server * DVI cable x 2 for dual display Caution : The LCD drawer is hot-pluggable, but components of connected devices, such as the servers and KVM switch, may not be hot-pluggable.
- Page 16 < Part 2 > < 2.1 > Product Specifi cations - RMD-X3K3 RMD-X3K3 Panel Native Resolution 3840 x 2160 Panel Size ( diagonal ) 17.3-inch TFT color LCD Brightness ( cd/m² ) Contrast Ratio ( typ. ) 1000:1 Colors 16.7 M, 8-bit...
- Page 17 < 2.1 > Product Specifi cations - RMD-X3K3 Physical Product ( W x D x H ) 441.6 x 550 x 88 Specifi cation inch 17.4 x 21.7 x 3.5 Packing ( W x D x H ) 580 x 683 x 197 inch 22.8 x 26.9 x 7.8...
- Page 18 < Part 2 > < 2.1 > Product Specifi cations - RMD-F17-3 / RMD-19-3 RMD-F17-3 RMD-19-3 Panel Native Resolution 1920 x 1080 1280 x 1024 Panel Size ( diagonal ) 17.3" 19" Brightness ( cd/m² ) Contrast Ratio ( typ. ) 600:1 1000:1 Colors...
- Page 19 < 2.1 > Product Specifi cations - RMD-F17-3 / RMD-19-3 Physical Product MRP-F17 441.6 x 550 x 88 Specifi cation ( W x D x H ) inch 17.4 x 21.7 x 3.5 MRP-19 441.6 x 600 x 88 17.4 x 23.6 x 7.8 inch Packing ( W x D x H ) 580 x 683 x 197...
- Page 20 Intentionally Left Blank P.16 UM-CV-751-RMD-Q318V1 www.rackmountsales.com...
- Page 21 < 2.2 > On-screen Display Operation ( OSD ) Power light Green = On Orange = Power saving Membrane Switch Function Power on / off LCD Display the OSD menu Scrolls through menu options and adjusts the displayed control (To auto adjustment by pressing the button for 5 seconds) Exit the OSD screen Toggle analog, digital &...
- Page 22 < 2.2 > On-screen Display Operation ( OSD ) - RMD-X3K3 Picture Brightness : Adjust the screen brightness Contrast : Adjust the difference between the image background ( black level ) and the foreground ( white level ) Black level : Adjust background black level of the screen...
- Page 23 < 2.2 > On-screen Display Operation ( OSD ) - RMD-X3K3 Reset Reset : Return the adjustment back to factory setting PIP mode : Enter into PIP / PBP setting - PIP MODE / PBP 2WIN ( Main screen + 1 sub screen ) /...
- Page 24 < 2.2 > On-screen Display Operation ( OSD ) - RMD-F17-3 / RMD-19-3 OSD Confi guration Page Image: for the brightness, contrast, color temp, red, green, and blue Geometry: for the auto adjust, H position, V position, phase and clock Video: for the colour, tint, sharpness, noise reduction, DCDi and TV Setup Audio:...
- Page 25 CCTV market. Designed for use with Crystal Image displays, a SDI input module can support up to 1080p @60Hz resolution without using additional space or power and it comes standard with a 2-year warranty. RMD-X3K3 Power Central Left Right...
- Page 26 < 3.2 > Options : HDMI video input RMD-X3K3: HDMI 2.0 HDCP 2.2 RMD-F17-3:HDMI 1.3 ( HDCP 1.3 ) RMD-19-3 : HDMI 1.2 ( HDCP 1.1 ) ( 1 ) In some circumstances, if the user connects the LCD to PC via HDMI port for video and audio signals, the LCD may display incorrectly on a full screen.
- Page 27 12-Volt 12-Volt 12-Volt 12-Volt Output current: 4.16A 4.16A 4.16A 4.16A Effi ciency DC power RMD-X3K3 Central Left Right RMD-F17-3 / RMD-19-3 DVI-D Central Left Right For DC power option : ( 1 ) If the unit with LCD, earthing may be required ( 2 ) DC option excludes AC power adapter and power cord.
- Page 28 The company reserves the right to modify product specifi cations without prior notice and assumes no responsibility for any error which may appear in this publication. All brand names, logo and registered trademarks are properties of their respective owners. UM-CV-751-RMD-Q318V1 www.rackmountsales.com...
