- Page 1 Toll Free : 1-888-865-6888 Tel : 510-226-8368 Fax : 510-226-8968 Email : sales@RackmountMart.com...
- Page 2 2U Rackmount LCD Keyboard Drawer User Manual RKP220 Series 20” LCD Optional KVM ․8, 16 Ports PS/2 KVM, single console...
-
Page 4: Table Of Contents
RKP220 User Manual Table of Content Table of Content Introduction Features Package Contents Optional Accessories Peripheral Products Important Safeguards Structure Diagram Dimension Diagram 10. LCD OSD Menu Operation LCD Membrane Diagram Main Menu P.10-13 Sub Menu Resolution Settings P.14 For Windows P.15 For SUN Servers 11. -
Page 5: Introduction
RKP220 User Manual Introduction RKP Series is a combination of keyboard, mouse and monitor into a drawer, with features such as flip-up design, adjustable brackets, built in LCD OSD to provide effective assistant for an administrator to control PC system. RKP Series provides cost effective for your limited IT budget over using CRT and rack mounting. -
Page 6: Package Contents
RKP220 User Manual Package Contents LCD Keyboard Drawer 1 Piece User Manual 1 Piece DC Power Adapter 1 Piece Power Cord 1 Piece Mounting Bracket 1 Pair Fasteners 4 Pieces CD-6 3-in-1 KVM cable 8 Pieces Before Unpacking It is very important to locate the LCD Keyboard Drawer in a suitable environment. The surface for placing and fixing the LCD Keyboard Drawer should be stable and level or ●... -
Page 7: Optional Accessories
RKP220 User Manual Optional Accessories KVM Cable CD-6 / CD-10 / CD-15 6ft / 10ft / 15ft PS/2 3-in-1 cable Cascade Cable CA-2 / CA-6 / CA-10 / CA-15 2ft / 6ft / 10ft / 15ft PS/2 3-in-1 cable Conversion Adapter SUN-31 SUN / iMac USB to PS/2 adapter Others... -
Page 8: Important Safeguards
RKP220 User Manual Important Safeguards Please read all of these instructions carefully before you use the device. Save this manual for future reference. Unplug the LCD Keyboard Drawer from the power outlet before cleaning. ● Do not spray liquid cleaners or aerosol directly on the device. Wet a cloth with a ●... -
Page 9: Structure Diagram
RKP220 User Manual Structure Diagram Keyboard Aluminium front panel Class A active matrix TFT LCD panel Rear metal case LCD inverter LCD membrane Ball bearing telescopic slides with stopper Adjustable mounting bracket KVM switch module & membrane (KVM option only) Rev. -
Page 10: Dimension Diagram
RKP220 User Manual Dimension Diagram RKP220 2U 20” LCD Keyboard Drawer Side View Front View Top View 20” LCD Rev. : 2.0... - Page 11 RKP220 User Manual Session Rev. : 2.0...
-
Page 12: Lcd Osd Menu Operation
RKP220 User Manual LCD Session LCD Membrane Diagram Power Menu/Selection Auto Config Left Right LCD OSD Menu Operation Main Menu Image To enter into the Brightness, Contrast, Sharpness, Saturation, Hue sub- ● menu Geometry To enter into Auto Conflg., H. Position, V. Position, Clock, phase sub-menu ●... - Page 13 RKP220 User Manual LCD Session Image Brightness To adjust brightness level of the input signal Use the button to select the function, then use button to adjust from 0-100 Contrast To adjust the contrast level of the input signal Use the button to select the function, then use button to adjust from 0-100 Sharpness...
- Page 14 RKP220 User Manual LCD Session Geometry Auto Conflg To perform auto adjustment of the screen output. Use the button to select the function, then use the button to select “ Auto Conflg” H. Position To adjust Horizontal Position of the screen output. Use the button to select the function, then use the button to adjust “H.
- Page 15 RKP220 User Manual LCD Session Function OSD Position To perform OSD position selection of the screen Use the button to select the function, then use the button to select the digit for the OSD display region. OSD Zoom To perform OSD Zoom function of the OSD image Use the button to select the function, then use the button to on/off the OSD...
- Page 16 RKP220 User Manual LCD Session System Language To perform Language selection of the function display use the button to select suitable Use the button to select the function, then display language “ English”, “Chinese (中文)”, “Deutsch”, “Francais”, “Espanol”, “Italiano” and “Japanese (日本語)”. Time To perform time setting of the system.
-
Page 17: Resolution Settings
RKP220 User Manual LCD Session Resolution Settings For Microsoft Windows Step 1 – Press right click on the desktop Step 2 – Choose “Properties” Step 3 – Change the “Screen Resolution” Step 4 – Change the “Screen refresh rate” Rev. : 2.0 P.14... -
Page 18: For Sun Servers
RKP220 User Manual LCD Session For SUN Servers Resolution configuration procedures should be run by qualified SUN ● server administrator Sun Servers are using resolution at 1152 x 900 x 76Hz. ● Supported resolution mode for 15” LCD: ● 1024 x 768 x 70/75Hz Supported resolution mode for 17”, 19”or 20”... -
Page 19: Kvm Session
RKP220 User Manual Session Rev. : 2.0 P.16... -
Page 20: Front View
RKP220 User Manual KVM Session Front View Bank No. Selected Channel Bank Button Online Channel Channel Select Button Shift Button LED Indication Selected Channel - Displayed channel on monitor& red in LED. Channel select button - Press to select channel from 1 – 8. Shift button - Press &... -
Page 21: Rear View
RKP220 User Manual KVM Session Rear View Cascade Channel Power Port Port RKP220-801 RKP220-1601 DC Power -connect to external 12V DC power adapter. Cascade Port -connect to additional KVM switch for channel expansion. Channel Port -connect to PC computer with CD-6 3-in-1 KVM cable. Rev. -
Page 22: Installation Steps
RKP220 User Manual KVM Session Installation Steps Before installation, please make sure all of peripherals and computers have been turned off. Connect the 3-in-1cable with 2 mini-din 6-pin connectors and a HDDB 15-pin connector to the computer ports. Connect another end of the cable to KVM switch. Plug the power adapter included to the LCD Keyboard Drawer. -
Page 23: Cascading
RKP220 User Manual KVM Session Cascading Using CA-6 PS/2 KVM cable to connect from Bank 1’s “Cascade port” to Bank 2’s “Console port”. After connected please press “Bank” & “Channel” button on the front of the PS/2 KVM switch to reset the PS/2 KVM switch. Bank 1 CA-6 PS/2 KVM cable Bank 2... -
Page 24: Start Up
RKP220 User Manual Start Up The channels that have PC connected and it is switch on will have a green LED on that channel. The red LED will indicate the selected channel. 7 segments LED will display the bank number. Press channel button to select the channel. -
Page 25: Hot Key Command Operation
RKP220 User Manual Start Up Hot-key Command Operation Calling OSD Menu Scroll Scroll Space Bar Switch to Previous Port (powered on PC only) Scroll Scroll Switch to Next Power On Port (powered on PC only) Scroll Scroll Switch to Previous Bank First digit of Port Number: Scroll Scroll... - Page 26 RKP220 User Manual Start Up HotKey Command Operation Switch to Next Bank Scroll Scroll PgDn Enable / Disable beeper sound Scroll Scroll Note: The default Beeper function is ON and beeper control is only for Auto Scan for Powered on PC Scroll Scroll Reset to factory Default Setting...
-
Page 27: Osd Structure Diagram
RKP220 User Manual Start Up OSD Structure Diagram Bank Session BANK : 1 BANK : 1 SYSTEM 02 SYSTEM SYSTEM 02 E SYSTEM SYSTEM 03 SYSTEM 04 PC Session SYSTEM 03 SYSTEM 04 SYSTEM 05 SYSTEM 06 SYSTEM 05 SYSTEM 06 SYSTEM 07 SYSTEM 08 SYSTEM 07... - Page 28 RKP220 User Manual Start Up KVM Settings Session OSD Menu on screen time ● default is 10 seconds. It can be modified from 05 – 99 ● seconds. Scan Scan interval from one PC port ● to next PC port when applying █...
-
Page 29: 13. Faq
RKP220 User Manual 13. FAQ 1. Don’t press any keys on the keyboard while the selected computer is booting up. Otherwise, it might cause the keyboard error or keyboard is not detected at PC side. 2. The computer boot up fine, but keyboard doesn’t work. Make sure the keyboard works when directly plugged into the computer. -
Page 30: Technical Specification
RKP220 User Manual Technical Specification Item Description KVM Channel Port RKP220-801: 8 port / RKP220-1601 : 16 port KVM Channel Interface HDDB 15 pin PS/2 Keyboard: Mini Din 6 pin Female PC Computer Interface PS/2 Mouse: Mini Din 6 pin Female VGA : HDDB 15pin Female PS/2 Keyboard: Mini Din 6 pin Female Cascade Port Connector... - Page 31 60.0 (W) x 22.0 (H) x 77.0 (D) cm Packing Dimension 23.6 (W) x 8.7 (H) x 30.3 (D) inch RKP220 Series - approximate 20 / 24 kg Net / Gross Weight *All brand names, logo registered trademarks are properties of their respective owners.
